Yokogawa SPW482-13 Power Module Must-Have Fashion
Yokogawa SPW482-13 Power Supply Module: Product Overview and Specifications
The Yokogawa SPW482-13 is a high-performance industrial power supply module designed for use in various control and automation systems. Manufactured by Yokogawa, a leader in automation and control technologies, the SPW482-13 provides reliable, efficient, and stable power to meet the demanding requirements of industrial applications. It is specifically tailored for environments where high reliability, long life, and minimal downtime are critical.
This power supply module is part of the extensive Yokogawa product line, offering superior performance for powering control systems, automation equipment, and other industrial electronics. Whether for use in factory automation, process control, or equipment management systems, the SPW482-13 ensures stable and continuous power delivery, helping to avoid costly downtime and ensuring the smooth operation of critical systems.
Key Features:
- High Efficiency: The SPW482-13 boasts high operational efficiency, typically exceeding 90%, which helps to reduce energy consumption and lower operational costs.
- Wide Input Voltage Range: The power supply is designed to accept input voltages from 85V AC to 264V AC, making it suitable for use in a variety of locations with varying power conditions.
- Compact Design: Despite its high power output, the SPW482-13 is compact and space-efficient, allowing it to be installed in environments with limited space.
- Reliable Power Delivery: The SPW482-13 is engineered to provide continuous, stable output under fluctuating conditions, supporting the operation of sensitive equipment such as PLCs, controllers, and sensors.
- Protection Features: The module is equipped with multiple protection features, including overcurrent, short-circuit, and overload protection, to safeguard both the power supply and the connected equipment.
- Global Certifications: With certifications such as UL, CE, and RoHS, the SPW482-13 meets international safety and environmental standards, ensuring it is safe for use worldwide.
- Environmentally Friendly: In addition to being RoHS compliant, the SPW482-13 is designed to operate with minimal environmental impact, making it an ideal choice for companies focused on sustainability.
Applications:
- Factory Automation
- Process Control Systems
- Programmable Logic Controllers (PLC)
- Industrial Automation and Control
- Equipment and Control Systems for Critical Applications
Technical Specifications:
| Parameter | Specification |
|---|---|
| Model | SPW482-13 |
| Input Voltage | 85V AC – 264V AC, 47-63 Hz |
| Output Voltage | 24 V DC |
| Output Current | 20 A |
| Output Power | 480 W |
| Efficiency | > 90% |
| Ripple & Noise | < 150 mV (p-p) |
| Overload Protection | Yes (Automatic recovery) |
| Short Circuit Protection | Yes |
| Dimensions | 150 mm (W) x 120 mm (H) x 50 mm (D) |
| Weight | 1.1 kg |
| Operating Temperature | -10°C to +60°C |
| Storage Temperature | -20°C to +85°C |
| Humidity | 20% to 90% RH (Non-condensing) |
| Cooling | Natural Convection (Fanless) |
| Safety Certifications | UL, CE, RoHS, EN 60950-1, EN 61204-3 |
Additional Features:
- Fanless Operation: The SPW482-13 operates without the need for a fan, contributing to silent operation and minimizing the risk of mechanical failure due to fan wear.
- High Power Efficiency: With its energy-efficient design, the SPW482-13 reduces power consumption, which lowers operating costs and helps reduce the overall environmental footprint.
- Wide Operating Temperature: Capable of operating in a wide temperature range, the SPW482-13 ensures reliable performance in environments where temperature fluctuations are common, from -10°C to +60°C.
- Robust Protection Mechanisms: Designed with built-in overcurrent, short-circuit, and overload protections, the module prevents any damage to both the power supply and connected devices in case of power spikes or faults.
- Compact and Versatile Design: The SPW482-13 is compact and flexible, allowing it to be integrated into a variety of industrial control systems, automation applications, and factory setups.
Why Choose Yokogawa SPW482-13?
The SPW482-13 is an excellent choice for industries that require reliable power for their critical systems. The power supply offers high efficiency, strong protection features, and long-term durability, ensuring that industrial automation systems run smoothly without interruptions. With its compact form factor, ease of integration, and global certifications, the SPW482-13 is ideal for both existing systems and new installations. Its design also emphasizes energy efficiency, making it a cost-effective choice in the long run.
Recommendations for Related or Similar Models:
| Model | Output Voltage | Output Current | Power Output | Dimensions (W x H x D) | Weight | Safety Certifications |
|---|---|---|---|---|---|---|
| SPW483-13 | 24 V DC | 20 A | 480 W | 125 x 120 x 200 mm | 2.0 kg | UL, CE, RoHS |
| SPW484-13 | 24 V DC | 20 A | 480 W | 125 x 120 x 200 mm | 2.0 kg | UL, CE, RoHS |
| SPW485-13 | 48 V DC | 10 A | 480 W | 125 x 120 x 200 mm | 2.0 kg | UL, CE, RoHS |
| SPW482-12 | 24 V DC | 20 A | 480 W | 125 x 120 x 200 mm | 2.0 kg | UL, CE, RoHS |
| SPW484-12 | 24 V DC | 20 A | 480 W | 125 x 120 x 200 mm | 2.0 kg | UL, CE, RoHS |
| SPW480-13 | 24 V DC | 10 A | 240 W | 125 x 120 x 200 mm | 2.0 kg | UL, CE, RoHS |
| SPW486-13 | 12 V DC | 40 A | 480 W | 125 x 120 x 200 mm | 2.0 kg | UL, CE, RoHS |
| SPW487-13 | 5 V DC | 96 A | 480 W | 125 x 120 x 200 mm | 2.0 kg | UL, CE, RoHS |
| SPW483-12 | 24 V DC | 20 A | 480 W | 125 x 120 x 200 mm | 2.0 kg | UL, CE, RoHS |
| SPW488-13 | 24 V DC | 25 A | 600 W | 150 x 150 x 220 mm | 2.5 kg | UL, CE, RoHS |
Yokogawa SPW482-13 is in stock. Contact us for quick quotes and competitive prices.
