Yokogawa SNT411-13 Optical ESB Bus Repeater Module
Yokogawa SNT411-13 Optical ESB Bus Repeater Module: Product Overview and Specifications
The Yokogawa SNT411-13 is an optical ESB (Extended Serial Bus) repeater module designed for use within Yokogawa’s advanced control systems. This module serves as a signal booster and communication extension tool, ensuring reliable and efficient communication between control components over long distances. It is particularly suited for industries where distributed control systems (DCS) or process control applications require high-speed data transmission with minimal interference.
This module is integral to the ESB network, which allows multiple devices to be connected over long distances via optical fiber, offering excellent noise immunity and high data integrity. The SNT411-13 is a vital component for maintaining stable and fast communication between remote units and central controllers, especially in environments where electrical noise can cause disruptions in data transmission.
Key Features:
- Optical Fiber Communication: The SNT411-13 uses optical fiber for data transmission, offering superior noise resistance and high-speed communication. Optical fiber provides better signal integrity over long distances compared to traditional copper-based communication.
- Extended Bus Reach: By amplifying and retransmitting signals, the module can extend the reach of the ESB network, ensuring seamless communication across large industrial plants or distributed control systems.
- Compatibility: It is fully compatible with other Yokogawa ESB network components, ensuring smooth integration into existing systems. The module supports various communication protocols for easy data exchange.
- Compact Design: With its compact form factor, the SNT411-13 can be easily integrated into control panels with limited space. Its lightweight design also reduces installation complexity.
- Reliable Data Transfer: The SNT411-13 ensures that data transmission between devices remains stable, even over long distances. It minimizes the risk of signal loss or degradation, ensuring that control systems remain responsive and accurate.
- Wide Operating Range: The module operates in a wide range of industrial conditions, making it suitable for use in factories, process plants, and other facilities where reliability and performance are crucial.
- Industrial Grade: Built to withstand the rigors of industrial environments, the SNT411-13 is rugged and durable, capable of performing under challenging conditions such as temperature extremes, humidity, and vibration.
- Easy Installation: The module is designed for easy integration into the ESB network, with clear connection instructions and simple setup procedures, making it an excellent choice for rapid deployment in automation systems.
- Low Power Consumption: Designed to be energy-efficient, the SNT411-13 ensures low operational costs while maintaining high performance.
- Diagnostic Functions: The module includes built-in diagnostics to monitor the health and performance of the communication network, allowing users to quickly identify any issues and ensure continuous system operation.
Applications:
The Yokogawa SNT411-13 optical ESB bus repeater module is ideal for various industries that require reliable and extended communication for process control systems. Some common applications include:
- Process Control Systems: In industries such as chemical processing, oil and gas, and pharmaceuticals, where distributed control systems (DCS) are used to monitor and control multiple processes over long distances.
- Manufacturing Automation: For use in large-scale manufacturing facilities, where it is crucial to maintain stable communication between various machines and control systems across wide areas.
- Power Generation: In power plants, where the ESB network is used to control critical equipment such as turbines, generators, and auxiliary systems, ensuring reliable and uninterrupted operation.
- Oil and Gas: The SNT411-13 module is especially useful in oil and gas installations, where remote monitoring and control of equipment is essential, even in harsh or hazardous environments.
- Water Treatment Plants: For ensuring stable communication between various treatment units, sensors, and control systems, ensuring effective water quality management.
Technical Specifications:
| Parameter | Specification |
|---|---|
| Model | Yokogawa SNT411-13 |
| Module Type | Optical ESB Bus Repeater Module |
| Communication Type | Optical Fiber |
| Power Supply | 24 V DC |
| Power Consumption | 3.5 W |
| Digital I/O | 0 (Only for signal repeat functionality) |
| Mounting Type | DIN Rail Mountable |
| Operating Temperature | -10°C to +60°C |
| Storage Temperature | -20°C to +70°C |
| Humidity | 5% to 95% RH (Non-condensing) |
| Dimensions (W x H x D) | 142.5 mm x 130 mm x 32.8 mm |
| Weight | 0.3 kg |
| Certification | CE, UL, RoHS |
| Diagnostic Features | Built-in diagnostic functions for performance monitoring |
| Redundancy Support | Yes, supports network redundancy for higher availability |
Related Models:
| Model | Type |
|---|---|
| Yokogawa SNT412-13 | Optical ESB Bus Repeater Module |
| Yokogawa SNT413-13 | Optical ESB Bus Repeater Module |
| Yokogawa SNT414-13 | Optical ESB Bus Repeater Module |
| Yokogawa SNT410-13 | ESB Bus Controller Module |
| Yokogawa SNT402-13 | ESB Bus Communication Interface Module |
| Yokogawa SNT420-13 | Optical ESB Bus Repeater Module |
| Yokogawa SNT406-13 | ESB Bus Signal Isolation Module |
| Yokogawa SNT400-13 | ESB Bus Master Module |
| Yokogawa SNT417-13 | Optical ESB Bus Repeater Module |
| Yokogawa SNT405-13 | ESB Bus Communication Hub |
Yokogawa SNT411-13 is in stock. Contact us for quick quotes and competitive prices.
