Yokogawa SNT401-13 Optical ESB Bus Repeater Module: Product Overview and Specifications

The Yokogawa SNT401-13 is an optical ESB (Extended Serial Bus) repeater module designed for use in Yokogawa’s distributed control systems (DCS). It plays a crucial role in extending communication over long distances while maintaining high data integrity and ensuring that the control systems can communicate seamlessly. This module is optimized for use in environments where noise immunity and long-range signal transmission are essential.

The SNT401-13 is built to work within the ESB network architecture, which allows various devices to communicate over optical fiber, ensuring a robust and interference-free connection. It amplifies and retransmits signals, ensuring that the communication between remote units and central controllers remains stable, even over long distances. This makes it a vital component in large-scale industrial processes, where reliable data transmission is crucial.

Key Features:

• Optical Fiber Communication: The SNT401-13 utilizes optical fiber for signal transmission, offering superior resistance to electromagnetic interference (EMI) and radio-frequency interference (RFI). This ensures high signal integrity and faster data transfer over longer distances compared to traditional copper-based systems.
• Long-Distance Communication: This module enhances the communication range of the ESB network by repeating signals, allowing devices to remain connected over extended distances. It ensures that control systems can communicate across large industrial sites, such as factories, power plants, or remote monitoring stations.
• Compact and Lightweight: The SNT401-13 has been designed with a compact form factor, making it easy to integrate into existing control systems and equipment racks. The lightweight design also reduces installation complexity and makes the module an ideal choice for space-constrained environments.
• Reliable and Robust: The module is designed to maintain data integrity and reliability, even under harsh environmental conditions. It is well-suited for use in environments with high levels of electromagnetic interference or in locations where long-distance communication is required.
• Redundancy Support: The SNT401-13 supports redundancy for increased availability, ensuring that in the event of a failure, the communication network continues to function seamlessly. This is especially important in safety-critical systems where continuous data flow is required for the protection of personnel and equipment.
• Low Power Consumption: This module is designed to be energy-efficient, reducing operational costs while maintaining high performance. It operates with a low power consumption of just 3.5 W, making it an environmentally friendly option for industrial systems.
• Diagnostic and Monitoring Functions: The SNT401-13 includes diagnostic tools to monitor the health of the optical fiber connection and the overall communication network. These diagnostic features allow for quick identification of faults or degradation in communication, minimizing downtime.
• Easy Integration: The SNT401-13 is compatible with other Yokogawa ESB components, making it easy to integrate into existing systems. It is designed for simple installation and provides clear and easy-to-follow instructions for setup.
• Versatile Applications: The module is suitable for a wide range of industrial applications, including process control systems, manufacturing automation, power generation, and more. It can be used in any system that requires reliable and long-distance communication.

Technical Specifications:

Applications:

The Yokogawa SNT401-13 optical ESB bus repeater module is widely used in industries where communication across long distances is critical. Some of the common applications include:

• Process Control Systems: In industries such as chemicals, oil and gas, and pharmaceuticals, where real-time data from sensors, controllers, and actuators need to be reliably transmitted over long distances.
• Power Plants: For power generation systems that require continuous communication between control units and remote devices.
• Manufacturing Automation: In large manufacturing facilities, where data needs to be transmitted over long distances without signal degradation.
• Remote Monitoring: For systems that require remote monitoring, such as offshore oil rigs, remote substations, or large-scale agricultural systems.
• Transportation: In industries like railways and aviation, where various devices communicate over large areas or at remote locations.

Related Models:
