Yokogawa AAI543-H50/K4A00 Analog Output Module Original stock
Product Overview: Yokogawa AAI543-H50/K4A00 Analog Output Module
The Yokogawa AAI543-H50/K4A00 is a high-performance analog output module designed for industrial automation systems. It converts digital signals into analog current outputs, facilitating precise control of actuators and instrumentation within process control environments.
Key Features:
- High Channel Density: Offers 16 isolated channels, each capable of 4 to 20 mA current output, allowing for extensive control capabilities within a compact module.
- HART Protocol Support: Incorporates digital communication using the HART protocol, enabling enhanced diagnostics and configuration flexibility.
- Robust Isolation: Each channel is electrically isolated, ensuring signal integrity and protection against interference.
- Compact Form Factor: Designed with dimensions of 107.5 mm (H) x 32.8 mm (W) x 130 mm (D) and a weight of 0.4 kg, facilitating easy integration into control systems.
- KS Cable Interface Adapter: Equipped with a KS cable interface adapter (model ATK4A-00) for seamless connectivity with AEA4D terminal boards.
Technical Specifications:
| Parameter | Specification |
|---|---|
| Model Number | AAI543-H50/K4A00 |
| Number of Channels | 16 isolated channels |
| Output Signal Range | 4 to 20 mA |
| Isolation Voltage | 1500 V AC between output and system for 1 minute |
| Accuracy | ±16 µA |
| Data Update Period | 10 ms |
| Dimensions (H x W x D) | 107.5 mm x 32.8 mm x 130 mm |
| Weight | 0.4 kg |
| Mounting | DIN rail |
| Operating Temperature | -20°C to +70°C |
| Storage Temperature | -40°C to +85°C |
| Humidity | 5% to 95% RH (non-condensing) |
| Power Consumption | 5 V DC, 0.9 A |
| HART Communication | Supported |
| Certifications | CE, UL |
Detailed Description:
The Yokogawa AAI543-H50/K4A00 analog output module is engineered to deliver precise and reliable current outputs for industrial automation applications. Each of its 16 channels supports a 4 to 20 mA signal range, commonly used in process control to represent various measurement parameters. The inclusion of HART protocol support allows for bidirectional digital communication, facilitating advanced diagnostics and remote configuration capabilities.
Electrical isolation between channels and the system is rated at 1500 V AC for one minute, enhancing safety and signal integrity by preventing interference and ground loops. The module’s compact dimensions and lightweight design make it suitable for installations where space is limited, without compromising performance.
The AAI543-H50/K4A00 is equipped with a KS cable interface adapter (model ATK4A-00), enabling straightforward connection to AEA4D terminal boards. This feature simplifies wiring and reduces installation time, contributing to overall system efficiency.
Designed for robust performance, the module operates effectively within a temperature range of -20°C to +70°C and can be stored in environments ranging from -40°C to +85°C. It functions reliably in humidity levels between 5% and 95% RH (non-condensing), ensuring adaptability to various industrial conditions.
With a power consumption of 0.9 A at 5 V DC, the module is energy-efficient, aligning with modern industrial sustainability practices. Compliance with CE and UL certifications underscores its adherence to international safety and quality standards.
Recommended Related Models:
For users seeking alternative or complementary modules within the same series or with related functionalities, the following models are recommended:
| Model Number | Description |
|---|---|
| AAI543-S50 | Analog Output Module with 16 channels, 4 to 20 mA output, without HART communication. |
| AAI543-H53 | Analog Output Module with 16 channels, 4 to 20 mA output, with HART communication and enhanced environmental resistance. |
| AAI543-S53 | Analog Output Module with 16 channels, 4 to 20 mA output, without HART communication, with enhanced environmental resistance. |
| AAI543-H60 | Analog Output Module with 8 channels, 4 to 20 mA output, with HART communication. |
| AAI543-S60 | Analog Output Module with 8 channels, 4 to 20 mA output, without HART communication. |
| AAI543-H61 | Analog Output Module with 8 channels, 4 to 20 mA output, with HART communication and enhanced environmental resistance. |
| AAI543-S61 | Analog Output Module with 8 channels, 4 to 20 mA output, without HART communication, with enhanced environmental resistance. |
| AAI543-SE0 | Analog Output Module with 16 channels, 4 to 20 mA output, with extended temperature range. |
| AAI543-SE3 | Analog Output Module with 16 channels, 4 to 20 mA output, with extended temperature range and enhanced environmental resistance. |
| AAI543-H00 | Analog Output Module with 16 channels, 4 to 20 mA output, with HART communication, basic type. |
Yokogawa AAI543-H50/K4A00 is in stock. Please contact us for a quick quote and competitive pricing.
