Product Overview

The Schneider 140AVO02000 is a high-performance analog voltage output module designed specifically for Modicon Quantum PLC systems. This module provides the ability to output analog voltage signals to control various devices or processes in industrial applications. With 4 output channels, it enables precise control of devices such as actuators, valves, motors, and other equipment that require analog voltage signals for operation.

The 140AVO02000 supports a wide output range, typically 0-10V, and offers 12-bit resolution for accurate voltage control. It integrates seamlessly into the Modicon Quantum I/O racks, ensuring smooth communication with other modules in the system. The module is particularly suitable for applications where precise analog control is required, such as temperature control, position control, speed control, and signal conditioning in industries like manufacturing, energy management, and process control.

This module is built to operate in harsh industrial environments, offering reliable performance with fast signal processing and low power consumption. The 140AVO02000 ensures efficient data handling, making it ideal for real-time control applications that require accurate and continuous output regulation.

Key Features

• 4 Analog Voltage Output Channels: Allows simultaneous control of multiple devices, ideal for applications requiring several output signals.
• Output Range: Supports output voltage from 0-10V, suitable for a wide range of industrial control applications.
• 12-Bit Resolution: Provides high-precision control with 12-bit resolution for fine adjustments and stable output.
• Fast Signal Processing: Facilitates real-time control and monitoring, ensuring rapid response in industrial systems.
• Compact Design: Small footprint for efficient integration into Modicon Quantum PLC systems, saving space in control panels and racks.
• Low Power Consumption: Designed with energy efficiency in mind, minimizing operational costs.
• Wide Operating Temperature Range: Can operate in a temperature range from 0°C to 60°C, suitable for various environmental conditions.
• Durable Construction: Built to withstand industrial environments, ensuring longevity and reliable performance in harsh conditions.
• Integrated Diagnostics: Features built-in diagnostics for continuous monitoring of the module’s health and status.

Applications

The Schneider 140AVO02000 is ideal for a wide range of industrial and automation applications, including but not limited to:

• Process Control: Outputting control voltages to actuators, valves, or pumps in process industries such as chemical processing, oil & gas, and pharmaceutical manufacturing.
• Factory Automation: Controlling various devices such as conveyors, motors, or positioning systems in automated manufacturing and production lines.
• HVAC Systems: Providing voltage output for controlling heating, ventilation, and air conditioning systems in large buildings or industrial plants.
• Energy Management: Sending control signals to equipment used in energy distribution, such as solar power inverters, generators, or transformers.
• Test & Measurement: Providing precise control voltages in laboratory applications or testing systems requiring specific voltage output levels.
• Building Automation: Used in lighting control systems, energy metering, and other building automation systems.

Technical Specifications

Detailed Product Features

1. 4 Analog Voltage Output Channels

The 140AVO02000 comes with 4 output channels, making it ideal for applications requiring control of multiple devices. This feature allows simultaneous control of up to four separate actuators or systems, offering enhanced flexibility in industrial control scenarios.

2. 12-Bit Resolution

The 12-bit resolution enables the module to output 4096 discrete voltage levels between 0V and 10V. This high resolution ensures fine-grained control over voltage output, crucial for applications requiring precise adjustments to regulate equipment performance.

3. Output Voltage Range

The module supports an output range of 0-10V, making it compatible with a wide variety of industrial equipment, including actuators, valves, and motors. This range allows the module to provide the correct voltage to drive many different types of systems and devices.

4. Fast Signal Processing

The 140AVO02000 is designed for real-time control and fast signal processing. This feature ensures that output voltage signals are updated quickly, allowing the system to respond to changes in real time, which is crucial for dynamic control systems.

5. Input-to-Output Isolation

The module provides input-to-output isolation, ensuring that any disturbances or faults in the output do not affect the input side of the system. This isolation helps maintain the integrity of the control process and prevents interference between different system components.

6. Compact and Robust Design

The 140AVO02000 is designed for easy integration into Modicon Quantum I/O racks. Its small size allows it to fit in confined spaces while still offering a reliable and robust solution for industrial applications.

7. Low Power Consumption

The module is designed with low power consumption, typically requiring only 0.6W of power to operate. This feature ensures efficient energy use, helping reduce operating costs over time, especially in large control systems with multiple output modules.

8. Wide Temperature Range

Operating within a temperature range of 0°C to 60°C, the 140AVO02000 can function reliably in a wide variety of industrial environments. It is suitable for use in areas where ambient temperatures can fluctuate, ensuring stable performance across different conditions.

9. Built-In Diagnostics

The 140AVO02000 module features built-in diagnostics for continuous monitoring of the module’s health and output status. This functionality helps prevent failures by providing early warnings of potential issues, allowing for proactive maintenance and troubleshooting.
