Honeywell FC-TSDO-0824 Digital Output Module Immediate Quote
Product Overview
The Honeywell FC-TSDO-0824 is a Safe Digital Output FTA (Field Terminal Assembly) module designed to offer reliable and precise control for industrial applications. This module supports 8 digital output channels, each capable of handling up to 1.5 A of continuous current, with a maximum voltage of 36 Vdc. The product is engineered for robust performance in harsh environments and complies with stringent safety and regulatory standards, including CE, TUV, UL, CSA, and FM certifications. The compact design and ease of installation make it suitable for a variety of industrial control systems, providing essential functionality for digital output control.
Key Features
- 8 Digital Output Channels: Allows for efficient control of multiple devices with independent outputs.
- High Continuous Current Capacity: Each output channel can handle up to 1.5 A continuous current, ensuring reliability.
- Wide Voltage Range: The module supports a maximum voltage of 36 Vdc, making it versatile for various applications.
- Industry Standard Mounting: The module is designed for easy mounting on DIN EN rails (TS32 / TS35 × 7.5), simplifying installation in control cabinets.
- Compact Dimensions: The compact size of 60 x 70 x 58 mm allows it to fit into limited spaces.
- Safety Certifications: The product is CE, TUV, UL, CSA, and FM approved, ensuring it meets high safety standards for industrial applications.
- Easy Wiring: Features screw terminals for quick and secure connections, with a maximum wire diameter of 2.5 mm² (AWG 14).
Technical Specifications
Dimensions and Weight
| Parameter | Value |
| Dimensions (D x W x H) | 60 x 70 x 58 mm |
| Weight | 0.5 kg |
General Information
| Parameter | Value |
| Product Type | Safe Digital Output FTA |
| Product Number | TSDO-0824 |
| Number of Channels | 8 |
| Mounting Type | DIN EN rails (TS32 / TS35 × 7.5) |
| Used Rail Length | 61 mm (2.40 in) |
| Screw Terminal Max. Wire Diameter | 2.5 mm² (AWG 14) |
| Strip Length | 7 mm (0.28 in) |
| Tightening Torque | 0.5 Nm (0.37 ft-lb) |
Electrical Specifications
| Parameter | Value |
| Maximum Voltage | 36 Vdc |
| Maximum Continuous Current per Channel | 1.5 A |
| Maximum Current (Defined by Connected Output Module) | Defined by module |
Approvals and Certifications
| Certification | Details |
| CE | Yes |
| TUV | Yes |
| UL | Yes |
| CSA | Yes |
| FM | Yes |
Industry Applications
The Honeywell FC-TSDO-0824 Digital Output Module is ideal for use in a variety of industrial sectors, including:
- Process Control: Used in systems requiring reliable and safe digital output control for actuators, relays, and other devices.
- Automation Systems: Essential for digital output tasks in industrial automation, ensuring efficient operations and monitoring.
- Manufacturing Facilities: Well-suited for controlling machinery and equipment, supporting operations that demand high accuracy and reliability.
- Energy and Utilities: Suitable for digital control tasks in power generation and distribution systems.
Honeywell FC-TSDO-0824 is in stock. Contact us for quick quotes and competitive prices.
