Honeywell CC-PWRB01 Power Supply Module 2 Days Delivery
1. Product Overview
The Honeywell CC-PWRB01 Power Supply Module is a core component of the Experion® Series C Control System, designed to provide efficient and reliable 24V DC power to compatible Series-C components. It supports redundant power configurations and provides backup battery support to ensure continuous system operation during power interruptions. The modular design ensures easy on-site maintenance, and the compact size makes it ideal for environments where power system stability and maintainability are critical.
2. Key Features
- Redundant Power Configuration: Supports dual power supply redundancy to ensure automatic takeover of the backup power supply in case of primary power failure.
- Battery Backup: The 20A power system offers optional battery backup to maintain operation for at least 30 minutes during a power outage.
- Modular Design: The “blade” design allows for easy field maintenance.
- Efficient Heat Dissipation: Innovative tilted electronic module design improves heat distribution, reducing overall size.
- Hot Swappable: Supports hot-swappable operation, allowing the power supply module to be replaced without powering down the system.
- Wide Range of Certifications: Complies with multiple international safety and environmental standards, making it suitable for installation in hazardous locations.
3. Technical Specifications
Dimensions and Weight
| Parameter | Specification |
| Dimensions | 160mm x 130mm x 40mm |
| Weight | 1.2 kg |
General Information
| Parameter | Specification |
| Operating Voltage | 100-230 VAC (input), 24-26 VDC (output) |
| Output Current | 0-20A (20A power system), 0-40A (40A power system) |
| Operating Temperature | 0°C to 60°C |
| Relative Humidity | 5% to 95% (non-condensing) |
| Efficiency | 65% (minimum) |
| Battery Backup | 30 minutes (20A power system only) |
Power Input and Output
| Parameter | Specification |
| AC Input Voltage | 100-230V VAC (rms) |
| Input Frequency | 47-63Hz |
| Output Voltage | 24-26VDC |
| Output Current | 0-20A (20A power system), 0-40A (40A power system) |
| Battery Backup Time | 30 minutes (20A power system only) |
Environmental and Durability
| Parameter | Specification |
| Transportation and Storage Temperature | -40°C to 85°C |
| Vibration Standard | 5 to 300Hz, max 1.07g (rms) |
| Mechanical Shock | 15g, 11ms, 3-axis shock |
| EMC Compliance | EN 61326-1:2013, IEC 61326-1:2012 |
4. Industry Applications
The Honeywell CC-PWRB01 power supply module is widely used in various industrial control systems, particularly in critical applications that require high reliability and redundant power. Common industries include:
- Oil and Gas: Providing reliable power support for automation systems in oil fields, drilling platforms, etc.
- Chemical and Pharmaceutical: Ensuring continuous operation of process equipment and monitoring systems in chemical and pharmaceutical manufacturing.
- Power and Energy: Supporting critical control devices in power plants and distribution networks.
Manufacturing: Ensuring the stable operation of automation systems on high-demand production lines.
Honeywell CC-PWRB01 is in stock. Contact us for quick quotes and competitive prices.
