HIMA F3113 8-Channel Output Amplifier Module – Product Description

The HIMA F3113 is an 8-channel output amplifier module designed for use in safety-related and high-reliability industrial applications. As part of the HIMA HIMax and HIMatrix safety systems, this module ensures safe and efficient signal amplification to drive actuators, solenoids, and other output devices. It is engineered to meet the highest standards of functional safety, making it suitable for applications in oil and gas, chemical processing, power generation, and railway automation.

This module is designed with redundancy and fail-safe mechanisms, ensuring continuous operation in mission-critical applications. It amplifies control signals and provides isolation between control systems and field devices, protecting the system from electrical disturbances and failures.

Key Features of HIMA F3113 8-Channel Output Amplifier Module

1. High-Performance Signal Amplification

   • The HIMA F3113 provides 8 independent output channels, allowing it to drive multiple field devices simultaneously.
   • It enhances weak control signals to ensure proper operation of solenoid valves, contactors, LED indicators, and other output devices.

2. Robust Electrical Isolation

   • This module provides galvanic isolation between control signals and output devices, protecting the PLC/DCS system from electrical faults.
   • Isolation helps prevent ground loops, overvoltage damage, and electromagnetic interference (EMI).

3. Integrated Diagnostic Functions

   • The F3113 includes built-in self-diagnostic features, allowing it to continuously monitor system health and detect faulty channels, short circuits, and overload conditions.
   • Fault indications can be transmitted back to the control system for real-time monitoring and maintenance.

4. Redundancy and High Reliability

   • Designed for fail-safe applications, the module supports redundant configurations, ensuring high availability in critical industrial processes.
   • It adheres to SIL (Safety Integrity Level) 3 standards, making it ideal for safety-critical environments.

5. Compact and Durable Design

   • The HIMA F3113 is designed to be compact while maintaining durability. It has a robust industrial-grade enclosure, ensuring protection against vibration, dust, and extreme temperatures.
   • With DIN rail mounting, it allows for easy installation in control cabinets and system enclosures.

6. Compatibility with HIMA Safety Systems

   • The module is fully compatible with HIMax and HIMatrix safety systems, allowing seamless integration into existing HIMA architectures.
   • It supports industry-standard communication protocols for easy connectivity with PLCs, DCS, and SCADA systems.

Technical Specifications of HIMA F3113 8-Channel Output Amplifier Module

Below is the detailed technical specification table for the HIMA F3113:

Applications of HIMA F3113 8-Channel Output Amplifier Module

The HIMA F3113 module is widely used in applications that require reliable signal amplification and electrical isolation. Some typical use cases include:

1. Oil and Gas Industry

• Used in pipeline safety systems, fire and gas detection, and emergency shutdown (ESD) systems.
• Ensures safe operation of solenoid valves and actuators in hazardous areas.

2. Chemical and Petrochemical Plants

• Used for controlling process valves, alarm indicators, and safety interlocks.
• Helps maintain process integrity by ensuring reliable signal transmission.

3. Power Generation and Distribution

• Provides safe and reliable signal amplification for switchgear control, turbine monitoring, and circuit breaker operation.
• Supports critical backup systems for preventing faults and downtime.

4. Railway Automation and Transportation

• Used for signaling systems, trackside control, and train protection.
• Ensures high-reliability operation in harsh railway environments.

5. Manufacturing and Industrial Automation

• Controls robotics, automated production lines, and conveyor systems.
• Enhances low-power control signals for industrial actuators and motors.

Certifications and Compliance

The HIMA F3113 meets international standards for safety and quality assurance, including:

• SIL 3 Certified (IEC 61508) – Ensures compliance with safety-critical applications.
• ATEX and IECEx Certified – Suitable for use in hazardous environments.
• CE Marked – Meets European safety and performance standards.
• TÜV Approved – Certified by TÜV Rheinland for functional safety compliance.
