Product Overview

The GE IC200PWB001H is an advanced I/O expansion module designed for GE Fanuc PLC systems, offering a high level of flexibility and scalability to meet the diverse needs of industrial automation applications. As part of the Versamax™ series, the IC200PWB001H module provides the essential communication and I/O interface that allows for seamless integration between GE PLCs and various field devices, such as sensors, actuators, and controllers.

This module is designed to expand the capabilities of the base PLC unit by providing additional discrete I/O channels, which enable real-time control and monitoring of various industrial processes. The IC200PWB001H supports high-speed communication and is ideal for applications requiring data collection, signal conditioning, and system integration.

With a robust design, the IC200PWB001H is built to operate reliably in harsh industrial environments, providing stable performance even in conditions such as temperature fluctuations, vibration, and electromagnetic interference (EMI). The module supports DIN rail mounting, making it easy to install and integrate into control panels and other industrial setups.

Key Features

• High-Performance I/O Expansion: The IC200PWB001H adds critical discrete I/O points to the GE Fanuc PLC, expanding the system’s ability to handle additional field devices.
• Modular Design: As part of the Versamax™ I/O system, it allows for easy scalability and flexible configuration based on the size and complexity of the application.
• Industrial-grade Build: Designed to meet the demands of industrial environments, the module features a rugged construction that provides durability against harsh conditions such as extreme temperatures, moisture, and vibration.
• DIN Rail Mounting: The module is designed for DIN rail mounting, simplifying installation and system integration into control cabinets.
• High-Speed Communication: The module provides fast communication between field devices and the central PLC, ensuring real-time data transfer for process control.
• Wide Application Compatibility: Suitable for use in a variety of industries including manufacturing, oil and gas, automotive, food processing, and chemical, among others.
• Compact and Space-Efficient: The module’s compact design allows for high-density mounting, making it a great choice for space-constrained environments.

Applications

The GE IC200PWB001H is ideal for a variety of industrial applications where expanding I/O capabilities and reliable performance are required. Some of the key applications include:

• Manufacturing: Used in automated production lines, conveyor systems, robotic arms, and assembly systems to increase I/O capacity and improve system efficiency.
• Oil and Gas: In critical upstream and downstream operations, the module provides reliable communication between sensors, valves, and control systems for monitoring pressure, temperature, and flow.
• Automotive: In vehicle manufacturing plants, the module facilitates real-time communication between various automated machines, including welding robots, conveyor belts, and quality control stations.
• Food Processing: For real-time control of mixers, packaging lines, fillers, and silos, ensuring the accuracy and efficiency of production.
• Chemical Processing: Ensures reliable I/O communication for controlling valves, reactors, and distillation columns in chemical plants.

Technical Specifications

Detailed Product Features

1. High-Performance I/O Expansion

The GE IC200PWB001H is designed to expand the I/O capacity of your GE Fanuc PLC system, adding up to 16 discrete inputs and 16 discrete relay outputs. This capability makes it ideal for systems requiring additional I/O points to accommodate a growing number of field devices.

2. Modular Design for Scalability

As part of the Versamax I/O series, the IC200PWB001H is designed to be modular and scalable, which makes it perfect for expanding an existing control system. Whether you need to add more I/O points to a single system or scale up for larger automation setups, this module allows you to customize your configuration.

3. Industrial-Grade Construction

Built with durability in mind, the IC200PWB001H is housed in a rugged plastic enclosure that provides protection against dust and moisture. With an IP20 rating, it is suitable for indoor use, where it can withstand environmental factors such as slight dust exposure and vibration, common in many industrial settings.

4. DIN Rail Mounting for Easy Installation

The DIN rail mounting option makes installation quick and easy. The module can be securely mounted in control cabinets and panels with minimal effort, reducing setup time and enhancing the system’s reliability.

5. Relay Output Functionality

The module features 16 relay outputs with a Form A contact configuration, suitable for controlling various devices such as motors, valves, and pumps. The relay outputs are rated at 250 V AC, 3 A (resistive load), ensuring compatibility with most industrial loads.

6. Reliable Power Supply

Operating with a 24 V DC power supply, the IC200PWB001H ensures reliable performance and is compatible with most industrial power systems. Its low current draw (approx. 150 mA) minimizes the load on the power supply, contributing to energy efficiency.

7. Flexible Input Types

The module’s input channels can be configured as sink or source, depending on the specific application and the type of input devices used. This flexibility provides compatibility with a wide range of field devices.

Benefits for Industrial Applications

1. Manufacturing: The IC200PWB001H is ideal for expanding automated production lines with additional I/O capabilities for controlling machines, conveyors, and robotic arms.
2. Oil and Gas: It provides reliable control over sensors, actuators, and valves for pressure, flow, and temperature measurements in upstream and downstream operations.
3. Automotive: The module enhances communication between robotic systems, conveyor systems, and assembly lines for real-time process control.
4. Food Processing: Ensures the accurate control of mixers, fillers, and packaging lines, optimizing production efficiency and reducing downtime.
5. Chemical Processing: The IC200PWB001H is ideal for real-time control of valves, pumps, and reactors in chemical plants, ensuring accurate process management.
