GE IC200ALG432B Analog Mixed Module Shelf life 1 year
Product Overview
The GE IC200ALG432B is a 32-channel analog input module designed for the VersaMax I/O system. It is specifically engineered to handle analog signals in industrial automation and control systems with exceptional accuracy, offering users the ability to monitor a large number of sensors simultaneously. This module is an essential part of the VersaMax PLC systems, providing flexible and reliable signal acquisition for various industrial applications.
Equipped with 16-bit resolution and supporting both voltage and current input types, the IC200ALG432B can be configured to meet the needs of complex control systems. The module supports up to 32 analog input channels, making it highly suitable for applications that require monitoring of multiple variables such as temperature, pressure, flow, and other process signals.
The module’s ability to handle a wide range of input types—including 0-10V voltage signals and 4-20mA current signals—makes it a versatile choice for process automation, machine control, and monitoring systems. Its high accuracy, input isolation, and fast data processing make it reliable even in harsh industrial environments with electrical noise.
Key Features
- 32 Analog Input Channels: Provides 32 input channels, allowing for the simultaneous processing of numerous analog signals.
- High Resolution (16-bit): Delivers high-precision data for fine control, with a 16-bit resolution ensuring accurate readings.
- Configurable Input Ranges: Supports voltage (0-10V) and current (4-20mA) input ranges, adaptable to various sensors.
- Input Isolation: Provides input-to-ground isolation, ensuring protection against electrical disturbances and enhancing signal integrity.
- Wide Operating Temperature Range: Suitable for use in environments ranging from 0°C to 60°C.
- Compact Design: Mounts easily onto a VersaMax I/O base, offering a modular, scalable solution.
- Low Power Consumption: Designed with efficiency in mind, operating at low power consumption.
- Real-Time Data Processing: Ensures fast data acquisition, making it ideal for applications requiring rapid control and feedback.
- Built for Harsh Environments: With high isolation and durable construction, it’s ideal for industrial environments prone to noise and electrical interference.
Applications
The GE IC200ALG432B is perfect for a wide range of applications in industries such as:
- Process Control: Used for monitoring temperature, pressure, flow, and other process variables, critical in industries like chemical, pharmaceutical, and oil & gas.
- Factory Automation: Integrated into manufacturing systems to monitor variables such as humidity, flow rate, and speed for automated machines, robotic arms, and assembly lines.
- Energy Management: In power plants and utility systems, this module can monitor electrical parameters such as current, voltage, and frequency.
- HVAC Control: Essential in building automation for controlling temperature, air quality, and energy efficiency.
- Test and Measurement: Used in measurement systems and test equipment for acquiring high-precision analog data in laboratories and field setups.
Technical Specifications
Feature | Specification |
---|---|
Model | GE IC200ALG432B |
Type | Analog Input Module |
Number of Channels | 32 Analog Inputs |
Input Types | Voltage (0-10V), Current (4-20mA) |
Input Range | Configurable: 0-10V, 4-20mA, and other custom ranges |
Resolution | 16-bit resolution |
Input Impedance | High input impedance for voltage inputs |
Accuracy | ±0.1% of full scale (typical) |
Power Supply | 24V DC (±10%) |
Operating Temperature | 0°C to 60°C |
Storage Temperature | -20°C to 85°C |
Dimensions | 110 x 66.8 x 50 mm |
Weight | 0.159 kg |
I/O Isolation | Input-to-ground isolation |
Power Consumption | Typically 0.75W |
Mounting Type | Mounts to VersaMax I/O base |
Signal Conditioning | Yes, internal signal conditioning for analog inputs |
Environmental Rating | IP20 (indoor use) |
Certifications | CE, UL Listed |
Data Transmission Rate | Fast data processing for real-time control systems |
Detailed Product Features
1. 32 Analog Input Channels
The GE IC200ALG432B features 32 input channels, providing a significant increase in I/O capacity compared to other modules in the VersaMax system. This makes it suitable for large-scale systems where multiple sensors need to be monitored simultaneously, such as in energy management systems, large industrial plants, and advanced control systems.
2. 16-Bit High-Resolution Processing
With 16-bit resolution, the IC200ALG432B provides precise measurements of analog signals, essential for accurate monitoring and control. The high resolution ensures that even small variations in analog input are captured, which is particularly important for processes where even minor fluctuations can have significant effects.
3. Configurable Input Ranges
The module supports multiple input types including voltage (0-10V) and current (4-20mA), as well as customizable ranges to meet the specific needs of a wide range of sensors and applications. This configurability makes the module versatile and adaptable for use in industries requiring different types of analog input signals.
4. Input Isolation for Enhanced Signal Integrity
The input-to-ground isolation feature protects against electrical noise, spikes, and other disruptions that are common in industrial environments. This ensures the signal integrity and reliability of the data, even in electrically noisy conditions, which is crucial for high-performance control systems.
5. Compact and Modular Design
The IC200ALG432B has a compact size which makes it ideal for installations where space is limited. Its modular design allows it to easily integrate with VersaMax I/O bases, enabling users to expand and customize their control systems as needed.
6. Low Power Consumption
The module operates with a low power consumption (typically 0.75W), making it an energy-efficient choice for industrial systems that run continuously. This contributes to cost savings over time and helps reduce the overall environmental impact of your system.
7. Fast Data Processing
The fast data processing capability of the IC200ALG432B makes it ideal for real-time control and feedback systems. It is suitable for applications that require rapid processing of analog signals, such as robotics, motion control, and automated manufacturing systems.
8. Wide Temperature Range
The module is designed to operate in environments with temperatures ranging from 0°C to 60°C, making it suitable for factory floors, power plants, and other industrial environments where temperature fluctuations can occur. It can withstand high-temperature conditions, ensuring reliability in diverse operating environments.
GE IC200ALG432B is in stock. Contact us for quick quotes and competitive prices.
