Product Overview

The GE IC200ALG264L is a highly reliable and versatile analog input module designed for use in Versamax I/O systems. This module is engineered to provide precise analog signal processing in industrial automation applications, allowing the conversion of real-world analog signals (such as voltage and current) into a format that can be read and processed by a programmable logic controller (PLC).

This particular model is equipped with 16 input channels, supporting a variety of input signal types including voltage, current, and resistance signals. It is ideal for industries that demand high-performance signal handling, such as manufacturing, chemical processing, power generation, and automotive production.

With the ability to accurately monitor and control processes involving analog inputs, the IC200ALG264L offers a reliable solution for critical industrial applications. Designed for rugged environments, the module operates efficiently under harsh conditions, including temperature variations, electromagnetic interference (EMI), and vibrations.

Key Features

• 16 Analog Inputs: The module supports up to 16 input channels with configurable voltage and current inputs. This feature makes it highly versatile for various applications requiring multiple channels of analog data.
• High Accuracy and Resolution: The IC200ALG264L ensures high precision with its 12-bit resolution, making it ideal for critical applications where accuracy is essential.
• Signal Isolation: Galvanic isolation between the analog inputs and the system ensures protection against electrical noise and voltage spikes, thus preventing interference in the data collection process.
• Wide Input Range: The module is capable of handling a wide range of input signals, from 0 to 10 V DC to 0 to 20 mA, making it compatible with numerous field devices.
• DIN Rail Mountable: Designed for ease of installation, this module can be mounted directly onto a DIN rail, ensuring quick and secure setup.
• Compact and Durable: The IC200ALG264L is built to withstand the challenging conditions of industrial environments, providing reliable performance in temperatures ranging from -20°C to 60°C and protection from dust and moisture with its IP20-rated enclosure.
• Status LED Indicators: Equipped with LED indicators for power, status, and communication, the module enables quick diagnostic checks and system troubleshooting.

Applications

The GE IC200ALG264L is widely used in industries that require precise measurement and control of analog signals. Its applications include:

• Manufacturing: Employed in automated production lines to monitor critical variables like temperature, pressure, flow, and level in manufacturing processes, ensuring optimal operation.
• Chemical Processing: Used to monitor and control chemical reactions, fluid levels, and flow rates in industries such as petrochemical production and pharmaceutical manufacturing.
• Power Generation: Widely used in power plants to monitor and control steam, water, and gas flow, as well as temperature and pressure, contributing to efficient energy production.
• Automotive: Implemented in automated assembly lines to measure and control robotic systems, conveyor speeds, and quality control in the automotive manufacturing process.
• Oil & Gas: Utilized for monitoring pressure, flow, and temperature in remote oil rigs, pumps, and valves to ensure the safe and efficient operation of critical processes.

Technical Specifications

Detailed Product Features

1. 16 Analog Input Channels

The IC200ALG264L module provides 16 channels of analog input, capable of handling a variety of signal types, including voltage, current, and resistance. This flexibility ensures that the module can be used in a wide range of applications, from temperature sensing to pressure monitoring and flow rate control.

2. High Accuracy and Resolution

The module provides 12-bit resolution, ensuring high accuracy in data conversion. With an input accuracy of ±0.1%, it delivers reliable readings that are essential for high-precision control applications in industries such as chemical processing, power generation, and automotive manufacturing.

3. Galvanic Isolation

The IC200ALG264L features galvanic isolation between the analog inputs and the PLC system. This isolation prevents ground loops, electrical noise, and voltage spikes from affecting the system’s performance, ensuring stable and accurate signal processing.

4. Wide Input Range

With support for a wide range of input signals, the IC200ALG264L can accept both voltage (0-10 V DC) and current (0-20 mA) inputs. This versatility allows it to interface with a variety of sensors, making it suitable for use in industries with diverse monitoring needs.

5. Status LED Indicators

Equipped with status LEDs, the module provides clear visual feedback regarding the operational status of the system. These LEDs indicate whether the module is receiving power, if it is in a fault state, and the current communication status, aiding in quick troubleshooting.

6. Compact and Space-Saving Design

The IC200ALG264L is designed with a compact form factor, measuring just 100 mm x 90 mm x 75 mm. This small size allows the module to be easily installed in control cabinets or panels, saving valuable space while still offering 16 channels of input.

7. Industrial Durability

Built for the harshest industrial environments, the IC200ALG264L operates reliably in temperatures ranging from -20°C to 60°C. The module also features an IP20 enclosure rating, offering protection against dust and moisture for indoor use.

Benefits for Industrial Applications

1. Manufacturing: The module’s ability to process multiple types of analog signals makes it essential for automated production lines, enabling precise control over temperature, pressure, level, and flow.
2. Chemical Processing: It is used to monitor chemical reactions, flow rates, and temperature in chemical plants, ensuring that operations remain within safe and optimal limits.
3. Energy Generation: In power plants, it helps monitor the pressure, temperature, and flow of key fluids, ensuring efficient power generation and stable system performance.
4. Automotive: In automated vehicle assembly lines, the module supports robotic systems, conveyor control, and quality assurance by monitoring key analog signals.
5. Oil & Gas: The IC200ALG264L plays a critical role in monitoring and controlling pressure, temperature, and flow in remote oil and gas fields, ensuring system reliability and safety.
