Product Overview

The GE IC200ALG260E is a high-performance analog input module designed for use with VersaMax I/O systems. This module provides 16 channels of analog input with high precision and configurability. It is ideal for industrial applications that require accurate monitoring of process signals such as temperature, pressure, flow, and level. The module is capable of handling both voltage and current input signals, offering flexibility for integration into various control systems.

Designed for high reliability and efficiency, the IC200ALG260E boasts a 16-bit resolution, ensuring fine-grained measurements for automated control systems and real-time feedback. Whether used in process control, factory automation, or building management systems, the IC200ALG260E is built to handle complex analog data streams with low power consumption and exceptional accuracy.

This module features a modular design, making it an easy addition to any VersaMax I/O system. Its rugged construction ensures that it can withstand the challenging conditions typically encountered in industrial environments, such as temperature fluctuations and electrical noise.

Key Features

• 16 Analog Input Channels: Provides 16 input channels, enabling users to monitor a range of analog signals simultaneously.
• High Resolution (16-bit): Offers 16-bit resolution for precise and accurate data collection.
• Configurable Input Types: Supports voltage (0-10V) and current (4-20mA) inputs, offering flexibility in various industrial applications.
• Wide Input Range: Can be configured for various voltage and current input ranges to accommodate different sensors.
• Low Power Consumption: Designed to operate with minimal power usage, reducing the operational cost over time.
• Real-Time Data Processing: Capable of processing data rapidly for real-time system feedback and control.
• Input Isolation: Ensures input-to-ground isolation for improved protection against electrical disturbances and noise.
• Compact and Modular Design: Easily mounts onto a VersaMax I/O base for seamless integration and scalability.
• Wide Operating Temperature Range: Built to operate in environments with temperatures ranging from 0°C to 60°C.
• Durable Construction: Designed to withstand harsh industrial conditions, ensuring reliability in demanding environments.

Applications

The GE IC200ALG260E module is designed for a wide range of industrial applications, including:

• Process Control Systems: Used to monitor variables such as temperature, pressure, flow, and level in industries like chemical, oil & gas, and pharmaceuticals.
• Factory Automation: Perfect for automated manufacturing systems, including assembly lines and robotic systems, where multiple analog inputs need to be processed quickly and accurately.
• Energy Management: Helps to monitor electrical parameters such as current, voltage, and frequency in power plants and substations.
• Building Automation: Used in HVAC systems and lighting control systems to monitor environmental factors like temperature, humidity, and air quality.
• Test and Measurement: Essential in laboratories and test setups for acquiring high-precision data from sensors.

Technical Specifications

Detailed Product Features

1. 16 Analog Input Channels

The GE IC200ALG260E offers 16 analog input channels, allowing for the simultaneous monitoring of multiple signals. This is particularly useful in applications where multiple sensors need to be read, such as temperature sensors, pressure transmitters, or flow meters.

2. 16-Bit High-Resolution Processing

With a 16-bit resolution, the module offers fine accuracy for all analog input signals. This high resolution ensures that even the smallest variations in input can be detected, making the module ideal for processes that require precise monitoring and control.

3. Configurable Input Types and Range

The module is capable of handling both voltage and current inputs, making it adaptable to different types of sensors. You can configure the input range for each channel to meet specific sensor requirements, whether it be 0-10V, 4-20mA, or custom input ranges. This flexibility makes it a versatile choice for a wide variety of industrial applications.

4. Input-to-Ground Isolation

The input-to-ground isolation feature ensures that any electrical interference or noise from the system is prevented from corrupting the data. This isolation is critical for ensuring the integrity of the analog signal, especially in high-noise environments such as large industrial plants or factory floors.

5. Low Power Consumption

With a typical power consumption of 0.75W, the IC200ALG260E module is energy-efficient and cost-effective. This is an important feature for long-term operations, where reducing energy consumption can lead to significant savings, particularly in systems that run continuously.

6. Real-Time Data Processing

The fast data processing capabilities ensure that the module can handle real-time monitoring and control tasks. This is essential in applications such as automation and robotics, where timely feedback is crucial for system performance.

7. Compact Size

The module’s compact design makes it easy to integrate into a VersaMax I/O base and fit into tight spaces. This modular approach allows for scalable and flexible system expansions.

8. Wide Temperature Range

The IC200ALG260E can operate in temperatures ranging from 0°C to 60°C, which makes it suitable for a wide range of industrial environments, from factory floors to energy plants. Its wide temperature tolerance ensures reliable performance in various conditions.
