Product Overview

The GE IC200ALG230A is a 16-channel analog input module designed for use in VersaMax PLC systems. It is designed to process analog signals with high precision and accuracy. The module is specifically engineered to interface with a wide variety of analog sensors, providing flexible signal conditioning and support for both voltage and current inputs. This makes it ideal for a range of industrial applications, including process control, automation, energy management, and measurement systems.

With user-configurable input ranges, the IC200ALG230A can handle signals like 0-10V, 4-20mA, and other common industrial ranges. This flexibility ensures compatibility with many types of sensors and instruments, making the module a versatile choice for industrial monitoring and control tasks. The 16-channel configuration also allows for efficient handling of multiple sensors, reducing the need for additional modules.

The module is built to be part of the VersaMax modular I/O system, enabling users to create scalable and customized control systems. With its 12-bit resolution and input isolation, the IC200ALG230A delivers high accuracy and signal integrity, even in environments with electrical noise or interference.

Key Features

• 16 Analog Input Channels: Supports 16 input channels, enabling the simultaneous acquisition of multiple analog signals.
• Configurable Input Ranges: The module supports 0-10V, 4-20mA, and other customizable input ranges, providing flexibility for a wide variety of industrial sensors.
• 12-Bit Resolution: Ensures high accuracy and fine granularity in reading analog signals, which is critical for process control applications.
• Compact and Modular Design: Easily integrates into the VersaMax I/O system with a small footprint, ideal for space-constrained installations.
• Input Isolation: Provides input-to-ground isolation, protecting the system from electrical noise, spikes, and other disturbances.
• Wide Operating Temperature Range: Operates effectively in a range of environmental conditions, from 0°C to 60°C.
• Low Power Consumption: Designed with energy efficiency in mind, the module operates at low power consumption to reduce operational costs.
• Fast Data Processing: Provides real-time signal processing for high-speed applications in control and automation systems.
• VersaMax Compatibility: Fully compatible with VersaMax I/O bases, allowing easy expansion and system customization.

Applications

The GE IC200ALG230A is used in a wide range of industries for monitoring and controlling analog signals. Some key applications include:

• Process Control: Used in industries like chemical processing, oil & gas, and pharmaceutical manufacturing, the module is crucial for accurate monitoring of process variables like temperature, pressure, and flow.
• Building Automation: Ideal for HVAC systems, energy management, and lighting control, the module supports monitoring parameters such as humidity, temperature, and light levels.
• Power Generation: The module is used in power plants and energy systems for monitoring voltage, current, and other critical electrical parameters.
• Factory Automation: In automated manufacturing environments, the module interfaces with sensors in robotic systems, CNC machines, and assembly lines to ensure smooth, controlled operations.
• Test and Measurement: Used in test equipment and measurement setups, providing high accuracy for analog readings in laboratory or field conditions.

Technical Specifications

Detailed Product Features

1. 16 Analog Input Channels

The GE IC200ALG230A is equipped with 16 input channels, allowing it to handle multiple analog inputs simultaneously. This makes the module highly suitable for systems where multi-point measurement is necessary, such as temperature control, pressure monitoring, and flow rate measurement.

2. Configurable Input Ranges

The module supports user-configurable input ranges to ensure compatibility with various types of sensors. It can handle 0-10V for voltage signals and 4-20mA for current signals. The flexibility to adjust input ranges makes the IC200ALG230A a versatile choice for a variety of industrial applications.

3. High Accuracy and 12-Bit Resolution

The 12-bit resolution ensures that the analog input signals are captured with high precision. This is particularly important for applications where small signal variations need to be monitored accurately. The ±0.1% accuracy guarantees that the analog data is reliable and consistent, making the module suitable for precision control.

4. Input Isolation

The input-to-ground isolation ensures that the system remains protected from electrical interference, voltage spikes, and ground loops. This feature helps to maintain the integrity of the data even in environments with significant electrical noise, ensuring reliable signal transmission.

5. Compact and Modular Design

The IC200ALG230A has a compact size which allows for easy installation in control panels or distributed I/O systems. It mounts easily onto a VersaMax I/O base, providing a scalable solution for expanding automation systems.

6. Low Power Consumption

With low power consumption (approximately 0.6W), the module is designed to be energy-efficient, minimizing operational costs and making it a sustainable option for long-term use in industrial systems.

7. Wide Temperature Range

The IC200ALG230A can operate in a temperature range of 0°C to 60°C, making it suitable for a wide variety of industrial environments. Whether in factory floors, energy plants, or outdoor installations, the module remains reliable and accurate in fluctuating conditions.

8. Fast Data Processing

The module processes analog input signals quickly, ensuring that real-time control operations can be performed. This is essential in applications where fast feedback loops are necessary, such as automated manufacturing and control systems in power generation.
