Emerson KJ3204X1-BA1 12P3275X022 32-Channel Digital Output Module
Emerson KJ3204X1-BA1 12P3275X022 32-Channel Digital Output Module
The Emerson KJ3204X1-BA1 (part number 12P3275X022) is a 32-channel digital output module designed for high-side switching applications within the DeltaV Distributed Control System (DCS). This module facilitates reliable and efficient control of field devices, making it integral to industrial automation processes.
Product Overview
The KJ3204X1-BA1 module provides 32 discrete output channels, each capable of sourcing 24 VDC to field devices such as solenoids, relays, and indicators. Its high-side switching configuration ensures that each output supplies current to the connected load, enhancing control reliability. The module’s robust design and compliance with industrial standards make it suitable for various industrial environments.
Key Features
-
High-Density Output Channels
- Offers 32 discrete output channels, allowing for extensive control capabilities within a compact module.
-
High-Side Switching
- Each channel sources 24 VDC to the connected load, ensuring reliable operation of field devices.
-
Robust Design
- Engineered to withstand harsh industrial conditions, including wide temperature ranges, shock, and vibration.
-
Efficient Power Management
- Optimized for low power consumption, reducing overall system energy requirements.
-
Seamless Integration
- Designed for easy integration with Emerson’s DeltaV DCS, facilitating straightforward installation and configuration.
Technical Specifications
| Parameter | Specification |
|---|---|
| Manufacturer | Emerson |
| Model Number | KJ3204X1-BA1 |
| Part Number | 12P3275X022 |
| Product Type | 32-Channel Digital Output Module |
| Output Channels | 32 |
| Output Voltage | 24 VDC |
| Output Current per Channel | 100 mA |
| Power Consumption | 12 VDC at 150 mA (LocalBus power); 24 VDC at 3.2 A (Bussed Field power) |
| Dimensions | 160 mm x 130 mm x 50 mm |
| Weight | 0.181 kg |
| Operating Temperature | -40°C to +70°C |
| Storage Temperature | -40°C to +85°C |
| Shock Resistance | 10g half-sine wave for 11 ms |
| Vibration Resistance | 1 mm peak-to-peak from 5 to 16 Hz; 0.5g from 16 to 150 Hz |
| Humidity | 5% to 95% non-condensing |
| Airborne Contaminants | ISA-S71.04-1985 Airborne Contaminants Class G3 |
| IP Rating | IP20 |
| Certifications | Hazardous Atmosphere II 3 G Nemko No. 02ATEX431U EEx nL IIC T4 |
Applications
The KJ3204X1-BA1 module is suitable for various industrial applications, including:
-
Process Control Systems
- Managing and controlling processes in industries such as oil and gas, chemical, and pharmaceuticals.
-
Manufacturing Automation
- Controlling machinery and equipment in automated production lines.
-
Power Generation
- Monitoring and controlling operations in power plants, including turbines and auxiliary systems.
-
Water and Wastewater Treatment
- Managing pumps, valves, and treatment processes in water facilities.
-
Building Automation
- Controlling lighting, HVAC, and security systems in commercial buildings.
Related Models
For users seeking modules with similar functionalities or additional features, Emerson offers a range of related models within the same series:
| Model | Description |
|---|---|
| KJ3201X1-BA1 | 16-Channel Digital Input Module, 24 VDC |
| KJ3202X1-BA1 | 16-Channel Digital Output Module, 24 VDC |
| KJ3203X1-BA1 | 8-Channel Analog Input Module, 4-20 mA HART |
| KJ3204X1-BA2 | 32-Channel Digital Output Module, 24 VDC High-Side, Series 2 |
| KJ3205X1-BA1 | 8-Channel Analog Output Module, 4-20 mA |
| KJ3206X1-BA1 | 16-Channel Thermocouple/mV Input Module |
| KJ3207X1-BA1 | 16-Channel RTD Input Module |
| KJ3208X1-BA1 | 8-Channel Isolated Analog Input Module, 4-20 mA |
| KJ3209X1-BA1 | 8-Channel Isolated Analog Output Module, 4-20 mA |
| KJ3210X1-BA1 | 32-Channel Digital Input Module, 24 VDC |
