Emerson KJ3102X1-BA1 12P1863X032 DeltaV Analog Input Module
Emerson KJ3102X1-BA1 12P1863X032 – DeltaV Analog Input Module
The Emerson KJ3102X1-BA1 12P1863X032 is a high-performance analog input module designed for integration with the Emerson DeltaV distributed control system (DCS) . This module is essential for acquiring real-time process data from various field instruments, including temperature sensors, pressure transmitters, and flow meters, thereby ensuring precise and reliable control over industrial processes.
Engineered for operational excellence, the KJ3102X1-BA1 12P1863X032 module offers features such as high-resolution analog-to-digital conversion, advanced signal filtering, and seamless integration within DeltaV systems. Its robust design makes it suitable for industries where accurate and dependable data acquisition is crucial.
Technical Specifications
| Specification | Details |
|---|---|
| Model Number | KJ3102X1-BA1 12P1863X032 |
| Product Type | Analog Input Module |
| Series | Emerson DeltaV |
| Number of Input Channels | 8 |
| Input Signal Types | 4–20 mA, 0–5 V, 1–5 V, 0–10 V, RTD, Thermocouple |
| Resolution | 16-bit Analog-to-Digital Conversion |
| Sampling Rate | 10 ms per channel |
| Accuracy | ±0.05% of full-scale range |
| Common Mode Rejection Ratio (CMRR) | 100 dB @ 60 Hz |
| Isolation | 2500V Optical Isolation Between Field and System |
| Diagnostics | Channel Diagnostics for Open Circuit, Over-Range, and Under-Range Detection |
| Communication Protocol | DeltaV Proprietary Network |
| Power Supply Voltage | 24V DC |
| Power Consumption | 3.5 W |
| Operating Temperature Range | -40°C to +70°C |
| Storage Temperature Range | -40°C to +85°C |
| Humidity Range | 5% to 95% RH (non-condensing) |
| Shock Resistance | 30g |
| Vibration Resistance | 2g (10–500 Hz) |
| Mounting Type | DeltaV I/O Carrier Backplane |
| Module Dimensions (W × H × D) | 44 × 102 × 108 mm |
| Package Weight | 0.22 kg |
| Certifications & Compliance | CE, UL, CSA, ATEX, IEC 61131-2 |
Key Features and Benefits
1. High-Accuracy Signal Processing
The module accurately measures analog signals from a wide range of industrial sensors with high precision and stability, ensuring consistent and reliable process control.
2. Multi-Signal Compatibility
It supports various input types, including 4–20 mA current loops, voltage signals, RTDs, and thermocouples, making it highly versatile for multiple industrial applications.
3. High-Speed Data Acquisition
With a 10 ms per channel sampling rate, the module ensures rapid and responsive data processing, reducing system latency and improving overall control system efficiency.
4. Advanced Diagnostics for Enhanced Reliability
Built-in channel diagnostics provide real-time monitoring for open circuits, short circuits, and signal range errors, allowing for proactive maintenance and troubleshooting.
5. Robust Industrial-Grade Design
- 2500V isolation for protection against electrical surges and noise interference.
- Wide operating temperature range (-40°C to 70°C), ensuring stability in harsh environments.
- Shock and vibration-resistant , making it ideal for demanding industrial applications.
6. Seamless Integration with DeltaV Systems
As part of the DeltaV automation platform, the KJ3102X1-BA1 provides plug-and-play compatibility, reducing engineering effort and simplifying system configuration.
Applications
The Emerson KJ3102X1-BA1 Analog Input Module is ideal for use in various industrial sectors, including:
- Oil & Gas Processing : Accurate monitoring of pressure, temperature, and flow in refining and pipeline operations.
- Power Generation : Reliable signal acquisition for boiler control, turbine monitoring, and emissions regulation.
- Chemical Manufacturing : Precision control for batch processing, mixing, and chemical reactions.
- Water & Wastewater Treatment : Monitoring pH levels, turbidity, and chemical dosing.
- Pharmaceutical & Food Production : Ensuring compliance with stringent regulatory requirements through precise environmental monitoring.
