Product Overview

The Emerson 960177-02 is an advanced level transmitter designed for industrial applications where accurate and reliable measurement of liquid levels, including those in pressurized environments, is essential. This product is widely used in industries such as chemical processing, water treatment, oil and gas, and pharmaceutical manufacturing, where consistent and precise measurement of liquid levels is critical for process optimization and safety.

The Emerson 960177-02 is based on advanced differential pressure (DP) measurement technology and can be used in various configurations, including high-pressure and high-temperature environments. With its stainless steel construction, it offers outstanding durability and reliability, making it a suitable choice for harsh conditions. This level transmitter features easy installation, long-term stability, and high accuracy, ensuring it meets the demanding requirements of modern industrial applications.

Key Features

• High Accuracy: Provides precise and stable measurements of liquid levels with a high degree of accuracy, typically within ±0.1% of span.
• Differential Pressure Measurement: Uses differential pressure technology for accurate level measurement, especially for pressurized tanks or vessels.
• Rugged Construction: Built with stainless steel housing for durability and resistance to corrosion, ideal for harsh industrial environments.
• Wide Operating Range: Suitable for measuring levels in a wide range of liquids, including chemicals, water, and oil, with pressures up to 100 bar.
• High-Temperature Tolerance: Can operate in temperatures ranging from -40°C to 125°C, making it suitable for high-temperature applications.
• Easy Installation: Comes with flexible mounting options, including flanged, threaded, and welded connections, ensuring compatibility with a variety of installations.
• Modular Design: Offers easy maintenance and serviceability due to its modular design, reducing downtime and service costs.
• Excellence in Safety: Designed to meet global safety standards, including ATEX and IECEx certifications, for use in hazardous environments.
• Long-term Stability: Features digital signal processing and advanced diagnostics, ensuring long-term operational stability and providing real-time alerts for potential issues.

Applications

The Emerson 960177-02 is well-suited for a range of industrial applications, particularly in sectors requiring high precision and reliable measurement of liquid levels. Common applications include:

1. Chemical Processing: Measurement of levels in chemical reactors, tanks, and pressure vessels.
2. Oil & Gas: Monitoring of crude oil tanks, refining equipment, and storage tanks to ensure consistent level control.
3. Water Treatment: Measurement of tank levels in water and wastewater treatment plants, ensuring proper management of water resources.
4. Pharmaceutical Manufacturing: Ensuring precise control of liquid levels in drug production tanks and bioreactors.
5. Power Generation: Used in boiler feedwater systems, steam drums, and cooling towers to monitor liquid levels critical to safe plant operation.

Technical Specifications

Detailed Product Features

1. High-Accuracy Measurement

The Emerson 960177-02 utilizes advanced differential pressure (DP) technology to provide accurate level measurements in tanks and vessels. It can detect the smallest variations in level, with an accuracy of ±0.1% of span. This precision is critical for industries such as chemical processing and pharmaceutical manufacturing, where even minor fluctuations in liquid levels can have significant consequences.

2. Wide Operating Pressure Range

With the ability to withstand pressures up to 100 bar (1450 psi), the Emerson 960177-02 is well-suited for applications in high-pressure environments such as oil and gas storage tanks and chemical reactors. This high-pressure tolerance ensures it can operate effectively in harsh conditions without compromising accuracy or reliability.

3. Temperature Compensation and High-Temperature Operation

The system incorporates automatic temperature compensation to ensure that readings remain accurate despite changes in temperature. It can operate in temperatures ranging from -40°C to 125°C, making it suitable for a wide range of industrial environments, including high-temperature processes in chemical plants and power generation facilities.

4. Flexible Mounting Options

The Emerson 960177-02 offers multiple mounting configurations, including flanged, threaded, and welded connections, making it compatible with a wide variety of process vessels, tanks, and pipes. The flexibility in mounting ensures easy installation in diverse industrial settings, reducing setup times and costs.

5. Durable Construction

Built with a stainless steel housing, the Emerson 960177-02 is highly resistant to corrosion, ensuring long-term durability in challenging environments. The unit is ideal for industries dealing with aggressive chemicals, harsh liquids, or extreme temperatures, maintaining its performance over time without requiring frequent replacements.

6. HART Protocol Support

This transmitter supports the HART protocol, providing users with the ability to integrate the device seamlessly into advanced control systems. The 4-20 mA analog output allows for easy communication with PLC or DCS systems, while the HART protocol enables additional diagnostics and configuration capabilities.

7. Real-Time Diagnostics

The Emerson 960177-02 comes equipped with real-time diagnostic capabilities that provide continuous monitoring of its health and performance. Operators can access valuable data on the transmitter’s operational status, helping to detect early signs of wear or performance degradation, thus preventing unplanned downtime and ensuring continuous process optimization.

8. Easy Maintenance

The modular design of the Emerson 960177-02 makes it easy to service and maintain. This reduces the need for complex repairs and long downtime, ensuring that the level transmitter remains operational and that maintenance schedules can be adhered to more effectively.

Applications in Industry

1. Chemical Processing: Utilized for measuring liquid levels in chemical reactors, storage tanks, and process vessels, ensuring the safe handling of volatile chemicals.
2. Oil & Gas: Used in oil storage tanks, refining equipment, and offshore platforms to ensure accurate liquid level monitoring under extreme pressures and temperatures.
3. Water Treatment: Critical for managing water tanks, wastewater systems, and pumping stations, ensuring efficient operation in water treatment facilities.
4. Pharmaceutical Manufacturing: Ensures precise liquid level measurements in bioreactors, fermentation tanks, and API manufacturing.
5. Power Generation: Ideal for use in boiler systems, steam drums, and cooling towers, where level monitoring is crucial for safe and efficient plant operation.
