ABB PM152 3BSE003643R1 Analog Output Module Price Advantage
Product Overview
The ABB PM152 3BSE003643R1 Analog Output Module is a key component of the ABB AC800F Freelance field controller system. Its primary function is to convert digital control signals from the AC800F system into analog output voltages or currents to drive actuators or other field devices requiring control signals. The PM152 module communicates with the AC800F base unit via the S800 bus, ensuring system stability and reliability. With high resolution and accuracy, the module provides precise control signals, making it suitable for various industrial automation applications.
Key Features
- High Precision Output: The PM152 module offers 12 or 16-bit high-resolution output, ensuring the precision and stability of control signals.
- Multiple Output Channels: The module typically features 8 or 16 isolated output channels, supporting various analog signal types, including single-ended voltage, differential voltage, and current output.
- Modular Design: The PM152 adopts a compact modular design, facilitating integration and expansion within AC800F racks.
- Diagnostic Functions: Built-in diagnostic tools enable real-time monitoring of module status and quick troubleshooting of signal or communication issues, enhancing system maintainability.
- Scalability: Supports multiple module connections, allowing users to flexibly expand the system’s analog output capacity as needed.
Technical Specifications
Dimensions and Weight
| Parameter Name | Value |
|---|---|
| Dimensions | 24 × 125 × 120 mm |
| Weight | 0.35 kg |
General Information
| Parameter Name | Value/Description |
|---|---|
| Model Number | PM152 3BSE003643R1 |
| System | ABB AC800F Freelance |
| Function | Digital to Analog Signal Output |
| Number of Output Channels | 8 or 16 Isolated Channels |
| Output Types | Voltage (Single-ended/Differential), Current |
| Resolution | 12 or 16-bit |
| Communication Interface | S800 Bus |
| Operating Temperature Range | -25°C to +70°C |
| Storage Temperature Range | -40°C to +85°C |
| Relative Humidity | 5% to 95% (Non-condensing) |
| Protection Rating | IP20 |
Electrical Characteristics
| Parameter Name | Value/Description |
|---|---|
| Output Voltage Range | 0-10 V, ±10 V |
| Output Current Range | 0-20 mA, 4-20 mA |
| Output Accuracy | ±0.1% Full Scale |
| Load Impedance (Voltage Output) | ≥ 1 kΩ |
| Load Impedance (Current Output) | ≤ 500 Ω |
Communication and Diagnostics
| Parameter Name | Value/Description |
|---|---|
| Communication Protocol | S800 Bus |
| Diagnostic Functions | Module Status Monitoring, Signal Fault Detection |
| Communication Rate | 1 Mbps |
Industry Applications
The ABB PM152 3BSE003643R1 Analog Output Module is widely used in industrial automation, particularly in scenarios requiring high-precision control signals. Below are its main application industries:
- Process Control: In industries such as chemicals, oil, and gas, the PM152 module is used to control valves, pumps, and other actuators, ensuring the stability and safety of production processes.
- Manufacturing: In automated production lines, the module is used to drive motors, servo systems, and other equipment, achieving precise motion control and process optimization.
- Energy Management: In power systems, the PM152 module is used to regulate the output of power generation equipment, ensuring the stable operation of the grid.
- Water Treatment: In water treatment and distribution systems, the module is used to control flow, pressure, and level, ensuring effective management and distribution of water resources.
ABB PM152 3BSE003643R1 is in stock. Contact us for quick quotes and competitive prices.
