ABB DO840 3BSE020838R1 Digital Output Module Cheap&Stock
Product Overview
The ABB DO840 3BSE020838R1 Digital Output Module is a 16-channel 24 V d.c. current sourcing output module designed for the S800 I/O system. Each channel can provide up to 0.5 A of continuous output current and features current limiting and over-temperature protection for safe and reliable operation. The module groups the 16 outputs into two isolated groups, each with 8 channels and a process voltage supervision input. The outputs are protected against overcurrent and over-temperature conditions, ensuring stable performance. The module also includes advanced on-board diagnostics and supports redundancy, making it ideal for applications that require high availability and reliability.
Key Features
- 16 Channels for 24 V d.c. current sourcing outputs
- Two Isolated Groups: 8 channels per group with process voltage supervision for each group.
- Current Limiting & Over-Temperature Protection: Each output channel features current limiting and over-temperature protection for safe operation.
- Optical Isolation: Provides electrical isolation to prevent interference.
- Module Monitoring & Diagnostics: Continuous monitoring with LED indicators for fault, run, warning, and output status.
- Redundancy Support: Suitable for both single and redundant applications.
- Advanced Error Detection: Automatically sets outputs to predetermined states upon error detection.
Technical Specifications
Dimensions & Weight
| Parameter | Specification |
| Width | 45 mm |
| Depth | 102 mm |
| Depth (with Connector) | 111 mm |
| Height | 119 mm |
| Weight | 0.15 kg |
General Information
| Parameter | Specification |
| Signal Specification | 24 V d.c. (19.2 – 32 V d.c.), 0.5 A |
| Number of Channels | 16 |
| Signal Type | Current Sourcing, Current Limiting |
| HART | No |
| SOE | No |
| Redundancy | Yes |
| High Integrity | No |
| Intrinsic Safety | No |
| Mechanics | S800 Series |
Isolation & Current Specifications
| Parameter | Specification |
| Isolation Type | Groupwise Isolated from Ground |
| Current Limiting | Short Circuit Proof |
| Maximum Field Cable Length | 600 meters |
| Rated Insulation Voltage | 50 V |
| Dielectric Test Voltage | 500 V a.c. |
Power & Current Consumption
| Parameter | Specification |
| Power Dissipation | Typ. 4.3 W |
| 5V ModuleBus Consumption | 130 mA |
| 24V ModuleBus Consumption | 0 |
| External 24V Consumption | 200 mA |
Diagnostics & Indications
| Parameter | Specification |
| Front LEDs | F(ault), R(un), W(arning), O(SP), Channel 1-16 Status |
| Supervision | Process Power 1 per Group |
| Error Indications | Module Error, Module Warning, Channel Error |
Environment & Certification
| Parameter | Specification |
| CE Mark | Yes |
| Electrical Safety | EN 61010-1, UL 61010-1, EN 61010-2-201, UL 61010-2-201 |
| Protection Class | IP20 (IEC 60529) |
| Operating Temperature | 0°C to +55°C |
| Storage Temperature | -40°C to +70°C |
| Relative Humidity | 5% to 95%, non-condensing |
| Pollution Degree | 2 (IEC 60664-1) |
| EMC | EN 61000-6-4, EN 61000-6-2 |
| Overvoltage Categories | IEC/EN 60664-1, EN 50178 |
Mechanical & Protection
| Parameter | Specification |
| Mounting | Vertical Installation |
| Enclosure Protection | No external protection |
| Corrosion Protection | ISA-S71.04: G3 |
Industry Applications
The ABB DO840 3BSE020838R1 Digital Output Module is used in industrial automation, building automation, power management, and process control systems. It is ideal for applications requiring current sourcing outputs and high reliability, such as process control systems, distributed control systems (DCS), and real-time monitoring systems.
ABB DO840 3BSE020838R1 is in stock. Contact us for quick quotes and competitive prices.
