1. Product Overview
The ABB DO802 3BSE022364R1 Digital Output Module is a high-performance 8-channel Normally Open (NO) relay output module designed for the S800 I/O system. This module supports both 110 V d.c. and 250 V a.c. output control, making it suitable for various industrial automation applications, especially in environments requiring reliable relay switching control. The DO802 employs advanced protection features, including short circuit, overvoltage, and overtemperature protection, ensuring greater safety and stability for users.
Each output channel is equipped with an optical isolator, output state indicator LED, relay driver, and EMC protection components, ensuring reliable long-term operation even in harsh environments. Additionally, the module features relay supply voltage monitoring, which can trigger error signals when the voltage is lost, transmitting this data through the ModuleBus.
2. Key Features
- 8 Output Channels: Supports 110 V d.c. and 250 V a.c. Normally Open (NO) relay outputs for a wide range of industrial applications.
- Independently Isolated Outputs: Each output channel is isolated to prevent electrical interference, enhancing system stability.
- Relay Supply Voltage Monitoring: Ensures that the relay operates correctly by monitoring the supply voltage, sending error signals in case of a voltage loss.
- Multiple Protection Features: Includes short-circuit protection, over-voltage protection, and over-temperature protection to safeguard the system and external equipment.
- Status Indicator LEDs: Each output channel has a state indicator LED, providing real-time status feedback for easier troubleshooting.
- Flexible Connections: Connections to process devices are made through detachable connectors, facilitating easy installation and maintenance.
- Industrial Certifications: Compliant with multiple industrial safety standards, making it suitable for high-load, high-voltage environments.
3. Technical Specifications
Dimensions and Weight
| Parameter | Value |
| Width | 86.1 mm |
| Height | 110 mm |
| Depth | 58.5 mm |
| Weight | 0.24 kg |
General Information
| Parameter | Value |
| Type | Digital Output Module |
| Signal Specification | 24V to 110V d.c. / 250V a.c. (max 2 A) |
| Number of Channels | 8 |
| Output Type | Relay (NO) Output |
| Mechanics | S800L |
Electrical Performance
| Parameter | Value |
| Output Voltage Range | 10V to 250V |
| Maximum Continuous Output Current | 2 A |
| Output Load | < 0.4 Ω |
| Rated Insulation Voltage | 250 V |
| Dielectric Test Voltage | 2000 V a.c. |
| Power Dissipation | Typ. 2.2 W |
| Current Consumption (+5V Modulebus) | Typ. 70 mA |
| Current Consumption (+24V Modulebus) | Typ. 80 mA |
| Current Consumption (+24V External) | 0 |
Environmental and Certification
| Parameter | Value |
| Operating Temperature | 0°C to +55°C (+32°F to +131°F) |
| Storage Temperature | -40°C to +70°C (-40°F to +158°F) |
| Relative Humidity | 5% to 95%, non-condensing |
| Protection Class | IP20 |
| Electrical Safety | Compliant with EN 61010-1, UL 61010-1 |
| Marine Certifications | ABS, BV, DNV, LR |
| RoHS Compliance | Compliant with Directive 2011/65/EU |
| WEEE Compliance | Compliant with Directive 2012/19/EU |
4. Industry Applications
The ABB DO802 3BSE022364R1 Digital Output Module is widely used in various industrial automation control systems, especially in applications that require relay control and remote switching of high-voltage electrical equipment. Typical applications include:
- Industrial Automation Systems: Provides reliable output control for industrial equipment, ensuring efficient operation of automation systems.
- Process Control Systems: Suitable for controlling valves, pumps, and other critical equipment in process automation.
- Remote Control Systems: Ensures reliable remote switching control of high-voltage electrical equipment.
- Redundant System Design: Ensures reliable outputs in redundant control systems for high availability environments.
High Voltage Control: Provides reliable output control in high-voltage and high-power load control, suitable for power facilities and their auxiliary equipment.
