ABB CI873AK01 3BSE092695R1 AC 800M Communication Interfaces Module Order online
1. Product Overview
The ABB CI873AK01 3BSE092695R1 AC 800M Communication Interface Module is a high-performance communication interface device designed for industrial automation control systems. This module supports the EtherNet/IP and DeviceNet protocols and is compatible with the ABB AC 800M controller series, enabling efficient data transmission and device control. The CI873AK01 module ensures reliable communication interfaces, facilitating efficient operation and real-time monitoring of industrial automation systems. It is widely used in industries such as power, oil, chemical, and manufacturing. Its modular design and industrial-grade reliability make it an ideal choice for industrial automation.
2. Key Features
- Supports EtherNet/IP and DeviceNet Protocols: Compatible with EtherNet/IP and DeviceNet communication standards, suitable for industrial automation networks.
- High-Performance Communication: Supports 10/100 Mbps transmission rates, meeting real-time control and monitoring needs.
- Module Redundancy Support: Supports 6 redundant pairs of CI873A modules, enhancing system reliability.
- Hot-Swapping: Supports hot-swapping for easy maintenance and upgrades.
- Industrial-Grade Reliability: Suitable for harsh industrial environments, ensuring long-term stable operation.
3. Technical Specifications
Dimensions and Weight
| Parameter Name | Value |
|---|---|
| Width | 59 mm |
| Height | 185 mm |
| Depth | 127.5 mm |
| Weight (including base) | 0.7 kg |
General Information
| Parameter Name | Value |
|---|---|
| Article Number | 3BSE092695R1 |
| Communication Protocol | EtherNet IP / DeviceNet |
| Master or Slave | Master |
| Transmission Speed | 10/100 Mbps |
| Line Redundancy | No |
| Module Redundancy | Yes |
| Hot Swap | Yes |
| Used with HI Controller | Yes |
Electrical Characteristics
| Parameter Name | Value |
|---|---|
| Max Units on CEX Bus | 12 |
| Connector Type | RJ-45 Female (8-pin) |
| 24V Typical Consumption | 160 mA |
Environmental Conditions
| Parameter Name | Value |
|---|---|
| Operating Temperature | +5°C to +55°C |
| Storage Temperature | -40°C to +70°C |
| Altitude | 2000 m (according to IEC/EN 61131-2) |
| Pollution Degree | Degree 2 (according to IEC/EN 61131-2) |
| Corrosion Protection | G3 compliant to ISA 71.04 |
| Relative Humidity | 5% to 95%, non-condensing |
| Protection Class | IP20 (according to EN60529, IEC 529) |
Certifications and Compliance
| Parameter Name | Value |
|---|---|
| CE Marking | Yes |
| Electrical Safety | UL 61010-1, UL 61010-2-201 |
| Hazardous Location | UL 60079-15, cULus Class 1, Zone 2, AEx nA IIC T4, ExnA IIC T4Gc X |
| Marine Certificates | DNV-GL (Pending: ABS, BV, LR) |
| RoHS Compliance | DIRECTIVE/2011/65/EU (EN 50581:2012) |
| WEEE Compliance | DIRECTIVE/2012/19/EU |
4. Industry Applications
The ABB CI873AK01 3BSE092695R1 AC 800M Communication Interface Module is widely used in the following industries:
- Power Industry: Used in substation automation systems for monitoring and controlling power equipment.
- Oil and Chemical: Suitable for process control systems, providing reliable communication interfaces.
- Manufacturing: Used in production line automation, supporting efficient control and data acquisition of equipment.
- Water Treatment Industry: Suitable for water treatment control systems, ensuring stable system operation.
ABB CI873AK01 3BSE092695R1 is in stock. Contact us for quick quotes and competitive prices.
