ABB CI840A 3BSE041882R1 PROFIBUS DP-V1 Interface Module Cheap&Stock
1. Product Overview
The ABB CI840A 3BSE041882R1 PROFIBUS DP-V1 Interface Module is a high-performance communication interface designed for industrial automation systems. It supports the PROFIBUS DP-V1 protocol, enabling efficient data exchange between the controller and field devices such as sensors, actuators, and remote I/O modules. This module is specifically designed for redundant applications and provides both line and module redundancy to ensure high system availability and fault tolerance.
With support for HART pass-through, input power fuse protection, and Hot Configuration In Run, the CI840A module provides flexible, reliable communication and supervision functions for industrial processes. It is compatible with ABB HI controllers like AC 800M, making it an ideal choice for automated systems in critical industries.
2. Key Features
- PROFIBUS DP-V1 Protocol Support: Provides high-speed data transmission and efficient communication between controllers and field devices.
- Redundancy Support: Supports both line and module redundancy for high availability and fault tolerance in critical applications.
- HART Pass-Through: Allows for the use of HART communication with field devices for enhanced diagnostic and control capabilities.
- Hot Swap: Facilitates module replacement without system downtime, ensuring continuous operation.
- Input Power Fuse Protection: Protects the system from electrical faults, enhancing safety and reliability.
- Compact and Reliable: Compact design for easy installation in control panels, with protection against harsh industrial environments.
3. Technical Specifications
Dimensions and Weight
| Parameter | Value |
|---|---|
| Width | 54 mm |
| Height | 119 mm |
| Depth | 96 mm |
| Weight | 0.2 kg |
General Information
| Parameter | Value |
|---|---|
| Product Number | 3BSE041882R1 |
| ABB Model Name | CI840A |
| Communication Protocol | PROFIBUS DP-V1 |
| Master or Slave | Slave |
| Line Redundancy | Yes |
| Module Redundancy | Yes |
| Hot Swap | Yes |
| Compatible with HI Controller | Yes |
Electrical Performance
| Parameter | Value |
|---|---|
| 24 V Consumption (typical) | 190 mA |
| Power Dissipation | 4.56 W |
Environmental and Certification
| Parameter | Value |
|---|---|
| Operating Temperature | 0°C to +55°C |
| Storage Temperature | -40°C to +70°C |
| Relative Humidity | 5% to 95%, Non-condensing |
| Protection Class | IP20 |
| Electrical Safety | IEC/EN 61010-1, UL 61010-1, EN 61010-2-201 |
| CE Mark | Yes |
| Hazardous Location | C1 Div 2 cULus, C1 Zone 2 cULus, ATEX Zone 2 |
4. Industry Applications
The ABB CI840A PROFIBUS DP-V1 Interface Module is widely used in industrial automation systems where reliable and high-speed communication is required. With support for redundancy and HART communication, it is perfect for industries such as manufacturing, process control, oil and gas, and power generation.
Typical applications include:
- Industrial Automation Control Systems: Efficient communication between controllers and field devices.
- Process Automation: Real-time data exchange between sensors, actuators, and controllers.
- Redundant Systems: Ensures system availability and fault tolerance in critical industrial applications.
- Oil and Gas Industry: Robust communication in harsh industrial environments.
- Power Generation: Supports automation and control in power plants.
ABB CI840A 3BSE041882R1 is in stock. Contact us for quick quotes and competitive prices.
