ABB AI835 3BSE008520R1 Analog Input Module Consulting Price
Product Overview
The ABB AI835 3BSE008520R1 Analog Input Module is a versatile and high-performance device designed for precise thermocouple and millivolt measurements. With 8 differential input channels, this module supports a wide range of thermocouple types (B, C, D, E, J, K, L, N, R, S, T, and U), making it suitable for various industrial applications. One of the channels can be configured as a “Cold Junction” (ambient) temperature measurement channel, which compensates for temperature variations in the connection points of the thermocouples. This feature ensures accurate temperature readings even in environments with fluctuating temperatures.
Key Features
- Differential Input Channels: 8 channels for thermocouple/mV measurements.
- Cold Junction Compensation: Channel 8 can be configured for cold junction temperature measurements.
- Wide Range of Thermocouples: Supports types B, C, D, E, J, K, L, N, R, S, T, and U.
- High Resolution: 15-bit resolution for precise measurements.
- Wire-Break Detection: Monitors inputs for open-circuit conditions.
- Versatile Mounting Options: Can be mounted vertically or horizontally.
- Robust Design: Suitable for harsh industrial environments.
Technical Specifications
| Parameter | Description |
| Article Number | 3BSE008520R1 |
| Type | Analog Input |
| Signal Specification | -30..75 mV linear; TC types B, C, D, E, J, K, L, N, R, S, T and U |
| Number of Channels | 8 |
| Mechanics | S800 |
| Resolution | 15 bits |
| Input Impedance | > 1 MΩ |
| Isolation | Groupwise isolated from ground |
| Error | Max. 0.1% |
| Temperature Drift | Typ. 5 ppm/°C, Max. 7 ppm/°C |
| Update Cycle Time | 280 + 80 * (number of active channels) ms at 50 Hz; 250 + 70 * (number of active channels) ms at 60 Hz |
| Maximum Field Cable Length | 600 meters (656 yards) |
| CMRR, 50Hz, 60Hz | 120 dB |
| NMRR, 50Hz, 60Hz | > 60 dB |
| Rated Insulation Voltage | 50 V |
| Dielectric Test Voltage | 500 V a.c. |
| Power Dissipation | 1.6 W |
| Current Consumption +5 V Modulebus | 75 mA |
| Current Consumption +24 V Modulebus | 50 mA |
| Current Consumption +24 V external | 0 |
| Diagnostics | Front LED’s F(ault), R(un), W(arning) |
| Supervision | Module error, reference channels, power supply low |
| Channel Error | Open-circuit |
| CJ-channel (ch 8) | < -40 °C (-40°F) and > 100 °C (212°F) |
| Status Indication of Supervision | Module Error, Module Warning, Channel error (8) |
| Environmental Compliance | CE mark Yes |
| Electrical Safety | EN 61010-1, UL 61010-1, EN 61010-2-201, UL 61010-2-201 |
| Hazardous Location | C1 Div 2 cULus, C1 Zone 2 cULus, ATEX Zone 2 |
| Marine Certification | ABS, BV, DNV, LR |
| Operating Temperature | 0 to +55 °C (+32 to +131 °F) |
| Storage Temperature | -40 to +70 °C (-40 to +158 °F) |
| Pollution Degree | Degree 2, IEC 60664-1 |
| Corrosion Protection | ISA-S71.04: G3 |
| Relative Humidity | 5 to 95%, non-condensing |
| Max Ambient Temperature | 55 °C (131 °F), for vertical mounting in compact MTU 40 °C (104 °F) |
| Protection Class | IP20 according to IEC 60529 |
| Mechanical Operating Conditions | IEC/EN 61131-2 |
| EMC | EN 61000-6-4 and EN 61000-6-2 |
| Overvoltage Categories | IEC/EN 60664-1, EN 50178 |
| Equipment Class | Class I according to IEC 61140; (earth protected) |
| RoHS Compliance | DIRECTIVE/2011/65/EU (EN 50581:2012) |
| WEEE Compliance | DIRECTIVE/2012/19/EU |
Industry Applications
The ABB AI835 3BSE008520R1 Analog Input Module is ideal for use in various industries where precise temperature measurements are critical. Some common applications include:
- Power Generation: Monitoring and controlling temperatures in power plants.
- Pulp and Paper: Ensuring optimal drying processes by accurately measuring temperatures.
- Chemical Processing: Maintaining strict temperature control during chemical reactions.
- Oil and Gas: Monitoring temperatures in refineries and offshore platforms.
- Food and Beverage: Ensuring accurate temperature control during production processes.
- Pharmaceutical: Maintaining precise temperature conditions for pharmaceutical manufacturing.
- HVAC Systems: Managing temperature controls in large-scale heating, ventilation, and air conditioning systems.
- Metalworking: Accurate temperature monitoring in furnaces and kilns.
ABB AI835 3BSE008520R1 is in stock. Contact us for quick quotes and competitive prices.
