ABB AI830A 3BSE040662R1 RTD Analog Input Module 2 Days Delivery
Product Overview
The ABB AI830A 3BSE040662R1 Analog Input Module is a sophisticated component designed for precise temperature measurement using Resistive Temperature Detectors (RTDs). This module is an essential part of industrial automation and control systems, offering high accuracy and reliability in diverse operational environments. With its 8-channel configuration, it supports various types of RTDs including Pt100, Cu10, Ni100, Ni120, as well as resistive sensors. The module features 3-wire connections for RTDs and ensures complete isolation from ground, enhancing safety and reducing noise interference.
Key Features
- 8 Channels for RTD Input: Supports Pt100, Cu10, Ni100, Ni120, and resistive sensor inputs.
- 3-Wire Connection: Simplifies wiring while maintaining high measurement accuracy.
- High Resolution: 14-bit resolution ensures precise temperature readings.
- Comprehensive Diagnostics: Monitors for open-circuit, short-circuit, and grounded sensor conditions.
- Isolation: Group-wise isolation from ground enhances signal integrity and safety.
- Configurable Mains Frequency Filter: Allows setting of notch filter cycles at 50 Hz or 60 Hz to mitigate mains frequency interference.
- Wide Operating Range: Operates within a temperature range of 0 to +55°C, suitable for various industrial settings.
Technical Specifications
| Parameter | Description |
| Article Number | 3BSE040662R1 |
| Type | Analog Input |
| Signal Specification | 3-wire RTD: Pt100, Cu10, Ni100, Ni120, and resistive |
| Number of Channels | 8 |
| Signal Type | See table in S800 Modules and Termination Units, 3BSE020924 |
| HART Communication | No |
| SOE Feature | No |
| Redundancy | No |
| High Integrity | No |
| Intrinsic Safety | No |
| Mechanics | S800 |
| Isolation | Group-wise isolated from ground |
| Error Dependency | Rerr = R * (0.005 + ΔR/100), Terr°C = Rerr / (R0 * TCR) |
| Update Cycle Time | 150 + 95 * (number of active channels) ms |
| CMRR, 50Hz, 60Hz | >120 dB (at 10Ω load) |
| NMRR, 50Hz, 60Hz | >60 dB |
| Rated Insulation Voltage | 50 V |
| Dielectric Test Voltage | 500 V a.c. |
| Power Dissipation | 1.6 W |
| Current Consumption +5 V | 70 mA |
| Current Consumption +24 V | 50 mA |
| Front LED Indicators | F(ault), R(un), W(arning) |
| Supervision | Open-circuit, short-circuit, reference channel, internal power supply |
| Status Indication | Module Error, Module Warning, Channel error (8) |
| Environmental Conditions | Operating: 0 to +55 °C; Storage: -40 to +70 °C |
| Humidity | 5 to 95%, non-condensing |
| Max Ambient Temperature | 55 °C (131 °F) |
| Pollution Degree | Degree 2, IEC 60664-1 |
| Corrosion Protection | ISA-S71.04: G3 |
| Protection Class | IP20 according to IEC 60529 |
| Mechanical Operating Conditions | IEC/EN 61131-2 |
| EMC Compatibility | EN 61000-6-4 and EN 61000-6-2 |
| Overvoltage Categories | IEC/EN 60664-1, EN 50178 |
| Equipment Class | Class I according to IEC 61140; (earth protected) |
| RoHS Compliance | DIRECTIVE/2011/65/EU (EN 50581:2012) |
| WEEE Compliance | DIRECTIVE/2012/19/EU |
| Compatibility | Use with MTU: TU810, TU812, TU814, TU830, TU833 |
| Keying Code | AF |
| Dimensions | Width: 45 mm (1.77”), Depth: 102 mm (4.01”), Height: 119 mm (4.7”) |
| Weight | 0.22 kg (0.49 lbs.) |
Industry Applications
The ABB AI830A 3BSE040662R1 Analog Input Module is ideally suited for applications in industries where precise temperature monitoring and control are critical. These include but are not limited to:
- Process Industries: Chemical processing, oil & gas, petrochemicals, where accurate temperature control is vital.
- Power Generation: Monitoring of generator temperatures to ensure efficient and safe operation.
- Food & Beverage: Precise temperature control during manufacturing processes to maintain product quality.
- Pharmaceuticals: Ensuring strict temperature conditions for storage and processing of sensitive medications.
- HVAC Systems: Integration into building management systems for precise climate control.
This module’s robust design, comprehensive diagnostic capabilities, and wide compatibility make it a versatile choice for various industrial automation and control applications, ensuring optimal performance and reliability under demanding conditions.
ABB AI830A 3BSE040662R1 is in stock. Contact us for quick quotes and competitive prices.
