ABB AI825 3BSE036456R1 Analog Input Module In Stock
Product Overview
The ABB AI825 3BSE036456R1 Analog Input Module is a high-performance signal acquisition device designed for industrial automation systems. It features 4 individually galvanic isolated channels supporting bipolar current and voltage inputs, ideal for high-precision signal measurement in harsh industrial environments. The module withstands accidental overvoltage up to +30 V d.c. on current inputs (protected by PTC resistors) and 6.3 V d.c. on voltage inputs. It is compatible with multiple signal types, including -20…+20 mA, 0…20 mA, 4…20 mA, -10…+10 V, 0…10 V, and 2…10 V, ensuring versatility across diverse industrial applications.
Key Features
- High-Precision Acquisition: 14-bit resolution with sign bit for accurate dynamic range.
- Full Galvanic Isolation: Each channel is isolated from system common and other channels (1900 V d.c. inter-channel, 3250 V d.c. channel-to-ground), minimizing noise interference.
- Robust Input Protection:
- Current inputs tolerate up to +30 V d.c. with PTC-based current limiting.
- Voltage inputs withstand 6.3 V d.c. direct current.
- Anti-Interference Capability: CMRR of 120 dB and NMRR exceeding 40 dB (50 Hz)/55 dB (60 Hz).
- Compact & Reliable Design: Compliant with S800 mechanics, IP20 protection, and operational stability in extreme conditions.
Technical Specifications
| Parameter | Details |
|---|---|
| Input Types | -20…+20 mA, 0…20 mA, 4…20 mA, -10…+10 V, 0…10 V, 2…10 V |
| Channels | 4 |
| Resolution | 14-bit plus sign |
| Input Impedance | 10 MΩ (voltage), 50 Ω (current) |
| Isolation | 1900 V d.c. (inter-channel), 3250 V d.c. (channel-to-ground) |
| Overvoltage Protection | Current: +30 V d.c.; Voltage: 6.3 V d.c. |
| Temperature Drift | 0~10 V: 47 ppm/°C; ±10 V: 34 ppm/°C; 0~20 mA: 78 ppm/°C; ±20 mA: 57 ppm/°C |
| Filter Response | Voltage: 115 ms (0-90%); Current: 130 ms (0-90%) |
| Update Cycle | <10 ms |
| Power Consumption | Typ. 2.5 W, Max. 3.2 W |
| Current Consumption | +5 V: Typ. 70 mA, Max. 100 mA; +24 V: Typ. 90 mA, Max. 110 mA |
| Dimensions (W×D×H) | 45 mm × 102 mm × 119 mm |
| Weight | 0.22 kg |
| Operating Temperature | 0~+55 °C (40 °C max. for vertical mounting) |
| Protection Class | IP20 (IEC 60529) |
| Certifications | CE, EN 61010-1, UL 61010-1, RoHS, WEEE |
Industry Applications
- Process Control: Real-time acquisition of pressure, flow, and temperature signals in chemical and oil industries.
- Power Systems: Voltage/current measurement in substations and distribution cabinets.
- Manufacturing: Integration with PLCs for sensor signal processing (e.g., displacement, tension).
- Environmental Monitoring: Data collection from sensors in wastewater treatment and air quality systems.
ABB AI825 3BSE036456R1 is in stock. Contact us for quick quotes and competitive prices.
