abb AI801 3BSE020512R1 Analog Input Module Immediate Quote
Product Overview
The ABB AI801 3BSE020512R1 Analog Input Module is a high-performance device engineered for industrial automation systems. Designed to handle the rigorous requirements of process control and monitoring, the AI801 offers extensive features that increase operational efficiency and accuracy. With its capacity to accommodate multiple channels for analog current inputs, this module provides a reliable solution for a variety of applications requiring precise data acquisition and monitoring.
The AI801 is specifically designed to handle unipolar single-ended current signals ranging from 0 to 20 mA and 4 to 20 mA. Its robust architecture is capable of withstanding potential short circuits to the transmitter supply without sustaining permanent damage, further enhancing its reliability in field applications. This module is ideal for integration into diverse control environments, making it a versatile choice for system designers and operators alike.
Key Features
- 8 Channels for Current Measurement: The AI801 supports eight independent channels for current inputs, allowing for simultaneous monitoring of multiple variables within a control system.
- Short-Circuit Protection: The module provides built-in protection against short circuits, capable of handling at least 30 V d.c. to the transmitter supply, ensuring long-term reliability.
- High Resolution: With a resolution of 12 bits, the AI801 delivers accurate and reliable readings, supporting enhanced process control.
- Input Resistance: The module features an input resistance of 250 ohms (including PTC), ensuring minimal impact on the overall circuit.
- Group Isolation: Each group of 8 channels is isolated from the ground, which helps to prevent noise and interference from affecting signal quality.
- Robust Connectors: The process and power connections are made via detachable connectors, facilitating simpler installation and maintenance.
- Monitoring Capabilities: The module is equipped with LED indicators to easily assess operational status and errors.
Technical Specifications
The following table outlines the key specifications of the ABB AI801 Analog Input Module, including dimensions and weight:
| Parameter | Specification |
|---|---|
| Article Number | 3BSE020512R1 |
| Type | Analog Input |
| Signal Specification | 0…20 mA, 4…20 mA |
| Number of Channels | 8 |
| Signal Type | Unipolar single-ended |
| HART | No |
| Resolution | 12 Bit |
| Input Impedance | 230 – 275 kΩ (including PTC) |
| Isolation | Groupwise isolated from ground |
| Under/Over Range | 0% / +15% |
| Maximum Error | Max 0.1% |
| Temperature Drift | Typ. 50 ppm/°C, Max. 80 ppm/°C |
| Input Filter (rise time 0-90%) | 180 ms |
| Update Cycle Time | 1 ms |
| Maximum Field Cable Length | 600 meters (656 yards) |
| Max Input Voltage (non-destructive) | 30 V d.c. |
| NMRR (50Hz, 60Hz) | > 40 dB |
| Rated Insulation Voltage | 50 V |
| Dielectric Test Voltage | 500 V a.c. |
| Power Dissipation | 1.1 W |
| Current Consumption +5 V Modulebus | 70 mA |
| Current Consumption +24 V Modulebus | 0 |
| Current Consumption +24 V External | 30 mA |
| Supported Wire Size | Solid: 0.05-2.5 mm², 30-12 AWG |
| Stranded: 0.05-1.5 mm², 30-12 AWG | |
| Recommended Torque | 0.5-0.6 Nm |
| Stripping Length | 6-7.5 mm (0.24-0.30 inch) |
| Dimensions | |
| Width | 86.1 mm (3.4”) |
| Depth | 58.5 mm (2.3”) |
| Height | 110 mm (4.33”) |
| Weight | 0.24 kg (0.53 lbs.) |
Industry Applications
The ABB AI801 Analog Input Module is versatile and can be applied in a multitude of industrial sectors where precise current measurement is critical. Common applications include:
- Manufacturing Process Control: The ability to monitor various process variables simultaneously makes this module ideal for manufacturing environments where maintaining optimal conditions is crucial.
- Energy Management: It is well-suited for applications monitoring energy consumption or control within electrical systems.
- Environmental Monitoring: The module can be employed in systems requiring the measurement of environmental parameters, such as air quality and fluid levels.
- HVAC Systems: It supports various HVAC applications, allowing for precise control parameters related to temperature and pressure.
- Research and Development: The module can be used in laboratories for experimental setups that require accurate current measurement in diverse applications.
