ABB Bailey IMFEC11 Analog Input Slave Module – Product Description

The ABB Bailey IMFEC11 is an analog input slave module designed for use with the Bailey INFI 90 distributed control system. This module is responsible for acquiring analog signals from field devices such as temperature sensors, pressure transmitters, level sensors, and flow meters. The IMFEC11 module converts these analog signals into digital data that can be processed by the control system for monitoring and controlling industrial processes in real-time.

The IMFEC11 module is ideal for applications requiring precise and reliable measurement of physical parameters. It is widely used in industries such as oil and gas, chemical processing, pharmaceutical, and power generation. The module provides high-quality data acquisition, enabling accurate process control and helping to ensure the stability and safety of operations.

This module is built with industrial-grade components, offering high accuracy, low signal distortion, and fast processing speeds. The IMFEC11 is designed to withstand harsh industrial environments, with the ability to handle temperature extremes, vibration, and electrical noise, making it suitable for deployment in demanding applications.

Key Features of ABB Bailey IMFEC11 Analog Input Slave Module

1. High-Precision Analog Signal Acquisition

   • The IMFEC11 provides high-precision analog signal conversion, supporting various types of analog sensors and instruments.
   • The module delivers accurate temperature, pressure, level, and flow readings to ensure precise data for process control.

2. Wide Input Range and Signal Types

   • The IMFEC11 supports a wide range of analog inputs, including 4-20 mA, 0-10 V, and 0-20 mA signals, making it versatile for a variety of industrial applications.
   • The module can interface with sensors that output voltage or current signals, offering flexibility in signal handling.

3. Compact and Durable Design

   • The module has a compact design, with dimensions of 132 mm x 25 mm x 125 mm, making it suitable for installation in control panels or cabinets with limited space.
   • Weighing just 0.567 kg, the IMFEC11 is easy to handle and install in different industrial environments.

4. Industrial-Grade Durability

   • The IMFEC11 is built to withstand tough industrial conditions. It is designed to function reliably in environments with extreme temperatures, electrical noise, and vibration.
   • The module complies with international standards for industrial automation and is suitable for deployment in a variety of sectors, including process control and safety monitoring.

5. Ease of Integration

   • The IMFEC11 is designed to seamlessly integrate with the INFI 90 control system, ensuring smooth communication between the module and other system components.
   • It supports both redundant configurations and hot swapping, offering flexibility for continuous operation in critical environments.

6. Advanced Diagnostics and Monitoring

   • The module includes built-in diagnostics to monitor the health of the system and detect any faults early.
   • Continuous self-checking features ensure that the system remains operational and minimizes downtime.

Technical Specifications of ABB Bailey IMFEC11 Analog Input Slave Module

Below are the detailed technical specifications for the ABB Bailey IMFEC11 analog input slave module:

Applications of ABB Bailey IMFEC11 Analog Input Slave Module

The ABB Bailey IMFEC11 analog input slave module is used in various applications where accurate measurement of physical parameters is essential. Some common use cases include:

1. Process Control Systems

• The IMFEC11 module is used to acquire analog signals from temperature sensors, pressure transmitters, and level sensors to monitor and control industrial processes.
• It is widely used in industries such as chemical processing, oil and gas, and pharmaceuticals to monitor and regulate process variables in real-time.

2. Power Generation

• In power plants and energy generation facilities, the IMFEC11 is used to measure variables like pressure, temperature, and flow, ensuring that equipment operates within safe and optimal parameters.
• The module provides critical feedback for monitoring the performance of turbines, boilers, and other power generation equipment.

3. Environmental Monitoring

• The IMFEC11 is used in environmental monitoring systems to acquire data from sensors measuring air quality, water quality, and pollutant levels.
• It enables accurate data collection and analysis for environmental compliance and reporting.

4. Manufacturing and Automation

• The module is used to monitor critical process variables in automated manufacturing systems. It supports precise measurement of parameters like temperature, pressure, and flow, contributing to improved product quality and system efficiency.
• In automated production lines, the IMFEC11 can interface with sensors to monitor conditions and ensure that machines operate within predefined thresholds.

Certifications and Compliance

The ABB Bailey IMFEC11 analog input slave module meets various industrial safety and quality standards, including:

• UL Listed: Complies with North American safety standards.
• CE Marked: Meets European Union regulations for health, safety, and environmental protection.
• CSA Approved: Complies with Canadian Standards Association safety standards.
• RoHS Compliant: Meets RoHS (Restriction of Hazardous Substances) environmental requirements.

Related Models in the ABB Bailey Series

The ABB Bailey IMFEC11 is part of the Bailey INFI 90 family of modules, and several other models offer additional functionality or enhanced features. Below are 10 related models:
